Specifications
- Recording MediaSD (512MB to 2GB) / SDHC card (4GB to 32GB)
- File SystemSD card: FAT16 / SDHC card: FAT32
- Input A-H
- XLR
- Connector: XLR-3-31 (1: GND, 2: HOT, 3: COLD), Balanced
- Input impedance: 2.4kΩ
- Nominal input level: –14dBu
- Maximum input level: +2dBu
- TRS
- Connector 1/4" (6.3mm): TRS phone jack, Balanced
- Input impedance: 22kΩ or more / 1MΩ (when INPUT H, GUITAR selected)
- Nominal input level: +4dBu
- Maximum input level: +20dBu
- XLR
- Stereo Out
- Connector: RCA pin-jack, Unbalanced
- Output impedance: 200Ω
- Nominal output level: –10dBV
- Maximum output level: +6dBV
- Effect Sends
- Connector: 1/4" (6.3mm) TS phone jack, Unbalanced
- Output impedance: 200Ω
- Nominal output level: –10dBV
- Maximum output level: +6dBV
- Monitor Out
- Connector: 1/4" (6.3mm) TRS phone jack, Balanced
- Output impedance: 200Ω
- Nominal output level: –2dBu
- Maximum output level: +14dBu
- Phones
- Connector: 1/4" (6.3mm) stereo phone jack
- Maximum output level: 70mW + 70mW (THD+N 0.1% or less, 32Ω loaded)
- USB
- Connector: USB Mini-B type 4-pin
- Format:
- USB2.0 High-Speed mass-storage class
- Remote
- Connector: 2.5mm TRS jack
- PowerDedicated AC adapter (PS-1220E or GPE248-120200-Z, included)
- Power consumption12W (when phantom power supplying)
- Dimensions (W × H × D)20.2 × 4.1 × 13.4 inches (514 × 100.4 × 336.9 mm)
- Weight13.67 lbs (6.2 kg)
