With advanced Chip On Board technology the Dotz Matrix from ADJ allows for a stunning display of Pixel Mapping or Wash effect from 9 powerful LEDs in a 4 x 4 arrangement. Get ready to create the a rich display of RGB mixed color at your next event.
With all it's great features like auto run, sound active mode, and built-in programs this DMX compatible LED fixture is easy to use and integrate into any entertainment production. This unit includes individual pixel control in DMX mode allowing you to fine tune your light display to suit any specific needs. Made from high quality materials the Dotz Matrix is built to last. Despite being high output and durable, this LED fixture is lightweight and will be easy to transport to wherever your next event may be. While portable, the Dotz Matrix has a high quality and powerful output making it ideal for theaters, venues, and night clubs. Get quality lighting you can trust with the Dotz Matrix LED Fixture from ADJ.
Utilizing Chip On Board technology the Dotz Matrix light fixture creates smooth and rich RGB color mixing and can be used as a Wash/Bar or Pixel Mapped for stunning visual effects. Also features 0-100% dimming, color macros and built-in shows. Great for stage lighting, bands, or night clubs.
ADJ Dotz Matrix Wash / Blinder LED Light Fixture Features
- Advanced Chip On Board technology produces powerful, smooth RGB color mixing with rich palettes of color
- 9 powerful LEDs in a 4 x 4 arrangement
- Auto run
- Sound active mode
- Individual pixel control in DMX mode
- Lightweight and portable
- Individual Pixel controllable in 48 & 53 channel DMX modes
- 4x Pixel Flip options changes pixel orientation
- Use as Wash/Blinder or Pixel Mapped matrix for a stunning visual effect
- Great for Stage Lighting, Bands or Night Clubs
- RDM Compliant (Remote Device Management)
- Built-In preset colors and programs
- Flicker Free operation (No flickering on camera)
- 5 selectable Dim Curves (Standard, Stage, TV, Architectural & Theatre)
- 60-degree beam angle
- 3 & 5-pin XLR chassis mount connectors for DMX linking
- With Wired Digital Communication Network
- Power AC IN/OUT to daisy chain power (up to 5 Dotz Matrix's @ 120V and 9 Dotz Matrix's @ 230V on one 20 amp circuit)
- 2630 LUX @2M; 730 LUX @4M (60-degree beam)
- 4-button DMX LCD display
- Single yoke allows fixture to be mounted
- Fan Cooled
- ETL Approved
- Dotz Matrix Wash / Blinder LED Light Fixture1
- 5 DMX channel modes 3, 6, 7, 48 & 53 channel
- 4x Operational modes Auto, Sound Active, Manual RGB Dimmer, Static Color, and DMX-512
- LED pulse and strobe effect Electronic Dimming 0 - 100%
- Power Draw 430W total (All LED's @ Full)
- Light Source 16x 30-Watt COB TRI LEDs (RGB: 3 in 1)
- Refresh Rate 3.6KHz
- Auto sensing power supply AC 100V/60Hz - 240V/50Hz
- Dimensions (LxWxH) 13.75 x 6.75 x 14.75 inches (345 x 170 x 370mm)
- Weight 18 lbs (7.8 kgs)
