Blaze Audio PowerZone Connect 122D DSP-Enabled Dante Power Amplifier

The PowerZone™ Connect 122D is a 125 W DSP-enabled Class-D amplifier with 2 channels and Dante™.

The PowerZone™ Connect 1U series is a line of DSP-enabled Class-D amplifiers designed to simplify the lives of system installers, providing unmatched reliability, efficiency, and exceptional system configuration. Their compact form factor makes them an ideal choice for audio/voice installation projects with limited space constraints, demanding high-output performance of up to 1000 W. The 1U family powers both conventional low-impedance (4Ω to 16Ω) loudspeakers and constant voltage (70V/100V) transformer-coupled loudspeakers, and features automatic power-sharing technology for proportional distribution in both Lo-Z and Hi-Z modes.

Specific models of the PowerZone™ Connect 1U amplifiers offer compatibility with Audinate Dante™ AoIP networks and installations. Our intuitive PowerZone™ Control web app is built into all our PowerZone™ Connect amplifiers for easy system setup. PowerZone™ Control facilitates effortless customization of even the most challenging audio/voice systems by delivering many DSP configuration options and tuning features, including multizone setup, input mixing, priority and ducking, restriction, input and output EQ, S/PDIF output routing, high-pass filter, speaker presets, delay, Wall-S1 controller configuration, Sine generator, and much more.

Blaze Audio PowerZone Connect 122D Features

• Ultra-compact ½-rack form factor
• Full-matrix DSP configuration via PowerZone™ Control web app (built-in)
• Audinate Dante® AoIP compatibility
• Hybrid power distribution in both Lo-Z and Hi-Z
• Powered by Pascal UMAC™ Class-D technology
• Flexible power sharing across output channels
• S/PDIF input/output
• Configurable GPIO
• ErP and Energy Star compliant
• UL listed audio equipment
• UREC™ universal power supply with PFC 5 Year warranty

• PowerZone Connect 122D DSP-Enabled Dante Power Amplifier1

• Output Power @ 4/8Ω2 x 60W
• Output Power @ 70/100V* 1 x 125W
• Total System Power 125W
• Power Consumption 75W
• Dimensions 1.7x8.7x8.4" (44x220x213mm)
• Weight 2kg (4.4 lbs)
