Blustream HD12DB 2-Way HDMI Splitter

The Blustream HD12DB has been designed to convert and downmix embedded 5.1ch Dolby Audio or DTS Audio within a HDMI signal into a stereo 2ch signal.

The HD12DB features a HDMI loop out to pass the original video and multi-channel embedded audio signal to compatible equipment, with a second HDMI output featuring video scaling of resolutions up to 4K @ 60Hz 4:4:4 video to various lower video formats. This provides the perfect cost-effective solution for ensuring that 4K UHD video and multi-channel audio can be distributed around a multi-room system where there are a mixture of 2ch and 5.1ch zones with multiple output resolution requirements.

Blustream HD12DB Features

• Features an in-built DAC (Digital to Analog audio Converter) that converts 5.1ch Dolby Audio or DTS Audio to a stereo 2ch signal available on HDMI, optical and analog audio outputs concurrently
• Supports the following audio input formats: Dolby 5.1, DTS-ES 6.1, DD+5.1, DD+2.0, PCM 5.1, PCM 2.0*
• Features 1 x HDMI input supporting 4K UHD video (4K @ 60Hz 4:4:4) that is replicated to 2 x HDMI outputs
• HDMI loop out will replicate the HDMI input signal up to 4K @ 60Hz 4:4:4 and 5.1ch Dolby Audio & DTS Audio
• HDMI audio breakout to down-mixed analog L/R audio and down-mixed optical digital outputs concurrently
• HDCP 2.2 compliant with advanced EDID management
• *Please Note: This product does not support decoding of DTS CD bitstreams. Playback of this format may produce undesirable noise.

• HD12DB 2-Way HDMI Splitter1
• 5V/3A DC Power Supply1
• Mounting Kit1
• Rubber Feet2
• Quick Reference Guide1

• Video Input Connectors 1 x HDMI Type A, 19-pin, female
• Video Output Connectors2 x HDMI Type A, 19-pin, female
• Audio Output Connectors 1 x Optical (TOSLINK), 2 x RCA analog Left / Right
• EDID4-pin DIP switch
• Resolution4-pin DIP switch
• Product Upgrade2 x Micro USB female
• Dimensions (W x H x D)127mm x 23mm x 104mm, without feet
• Shipping Weight1 kg
• Operating Temperature32°F to 104°F (0°C to 40°C)
• Storage Temperature-4°F to 140°F (-20°C to 60°C)
• Power Supply 5V/3A DC
• HDMI output 2 features a video scaler allowing the output resolution to be set to the following formats
  • 3840x2160 @ 60Hz
  • 3840x2160 @50Hz
  • 3840x2160 @ 30Hz
  • 3840x2160 @25Hz
  • 4K DCI @ 25Hz 4:4:4
  • 4K DCI @ 30Hz 4:4:4
  • 4K DCI @ 50Hz 4:4:4
  • 4K DCI @ 60Hz 4:4:4
  • 1920x1080 @ 60Hz
  • 1920x1080 @50Hz
  • 1280x720 @ 60Hz
  • 1280x720@50Hz
  • 1920x1200@ 60Hz
  • 1680x1050@ 60Hz
  • 1024x768@ 60Hz
