The Bose FreeSpace 3 Surface-Mount Acoustimass Bass Module is designed to provide surface-mount bass augmentation for new and existing background music systems. Features one 5.25" (133 mm) woofer that delivers deep bass down to 40 Hz without audible distortion.
Applications
- Retail stores
- Restaurants and bars
- Lobbies and conference rooms
- Wall-mounted speaker applications
Bose FreeSpace 3 Surface-Mount Features
- Low-frequency loudspeaker featuring one 5.25" woofer
- Acoustimass speaker technology filters out audible distortion to deliver non-localized bass
- Designed to work with the FreeSpace 3 surface and flush satellite speakers, or existing systems where additional bass reinforcement is desired
- Module design allows parallel connection of multiple bass modules (can accommodate 2 or 4 FreeSpace 3 satellites per bass module)
- Selectable 70/100V or low impedance
- FreeSpace 3 surface-mount Acoustimass bass module1
- Wall bracket1
- Frequency Response (+/- 3 dB)50 Hz - 230 Hz
- Frequency Range (-10 dB)40 Hz - 315 Hz
- Nominal Dispersionomnidirectional below 200 Hz
- Long-Term Power Handling
- 70/100 V: 200 W (800 W peak) mono
- Low Impedance: 50 W (200 W peak) per channel stereo or 100 W (400 W peak) mono
- Sensitivity (SPL/1W @ 1m)
- Per Channel: 76 dB SPL
- Mono: 79 dB SPL
- Max SPL @ 1m
- Per channel: 96 dB SPL (102 dB SPL peak)
- Mono: 102 dB SPL (108 dB SPL peak)
- Nominal Impedance5 Ω mono direct (transformer bypassed)
- Dimensions (LxW)7.5" x 14"
