The Canon EOS C70 offers exceptional cinema capabilities in a compact package. Enjoy stunning images with a 4K Super 35mm DGO Sensor and all the built-in features you could ask for, including ND Filters, mini XLRs, direct touch rotatable LCD screen, Dual Pixel CMOS Autofocus, and excellent battery life. Making the EOS C70 even more powerful is compatibility with Canon's expanding line of high-performance RF Lenses.

Canon EOS C70 Cinema Camera with 24-105 Lens Features

Canon Super 35mm Dual Gain Output (DGO) Sensor, 16+ stops of Total Dynamic Range
DIG!C DV7 Image Processor
Canon Log 2 and 3, PQ, and HLG Recording
RF Mount
EF Lens Compatibility with Mount Adapter EF-EOS R 0.71x
Direct Touch Control
Approved for use in Netflix productions
Firmware Available Summer 2023 Adds New Features:
Improvement to Clear Scan shutter mode
Improved Face Detection AF
Waveform Monitor/Vector Scope magnification
Adds support for Flex Zoom CN-E14-35MM T1.7 L S

Canon EOS C70 Cinema Camera1
24-105 Lens1

Imaging Sensor
- Effective Pixels
  - 4096x2160: when 4096 x 2160 or 2048 x 1080 is selected as the resolution (Approx. 8.85 megapixels)
  - 3840 x 2160: when 3840 x 2160 or 1920 x 1080 is selected as the resolution (Approx. 8.29 megapixels)
- Total Pixels: 4206 x 2280; Approx. 9.6 megapixels
- Sensor Type: CMOS
- Sensor Size
  - Super 35mm
  - 4K: 26.2 x 13.8 (29.6 mm diagonal)
  - UHD: 4K: 24.6 x 13.8 (28.2 mm diagonal)
- Sensor Modes: Super 35mm, Super 16mm(cropped)
- Pixel Pitch: 6.4 µm
- Scanning System: Progressive
- Number of Sensors: 1
- Filter: RGB Primary Color Filter (Bayer Array)
- Imaging Processor: DiG!C DV 7
Lens System
- Lens Mount: Default Mount: RF Mount
- Zoom/Focus Preset: Not Available
- Shockless Zoom: Not Available
- Digital Teleconverter: Not Available
- ND Filter: Mechanical ND filter system with option of clear, 2, 4, and 6 stops; 8 and 10 stops in extended mode
- Peripheral Illumination Correction: Available
- Chromatic aberration Correction: Available
- Distortion Correction: Available (RF Lenses only)
- Diffraction Correction: Available
Exposure and Metering
- Exposure Modes
  - (1) Manual exposure based on shutter setting, iris setting, ISO/gain setting, and ND filter setting
  - (2) Push auto iris control, auto iris control
  - (3) Auto ISO mode
- Metering Modes: Standard, Spotlight and Backlight
- Gain
  - Normal Setting -6dB to 54dB
  - Fine Setting -2dB to 54dB in 0.5 dB increments
- ISO: 100 to 102,400
- Auto Gain Control (AGC): Not Available
- Shockless Gain: Not Available
- Exposure Compensation/AE Shift: –2.0 to +2.0 in 0.25 point intervals
- Shutter Modes
  - 3 Modes: OFF; Speed; Angle; Slow Shutter; Clear Scan
  - Speed Mode is selected in 1/3 or 1/4 stop increments
- Shutter Speed Range
  - 59.94Hz/24.00Hz: 1/12 to 1/2000
  - 50.00Hz: 1/15 to 1/2000
- Shutter Angle Settings: 59.94Hz/50.00Hz/24.00Hz: 360, 240, 180, 120, 90, 60, 45, 30, 22.5, 15, 11.25
- Iris Settings (EF)
  - Can be set to 1/2 stop, 1/3 stop or Fine.
  - (1) Push auto iris control
  - (2) Auto iris control (Compatible lens required)
Focus
- Focus Control: Dual Pixel CMOS AF with EOSxITR
- Focus Modes
  - Manual focus, Continuous AF, One-Shot AF, AF-Boosted MF, Face Detection AF
  - Only lenses that support AF functions can be used in AF modes. Face Detection and Tracking AF in Slow & Fast recording modes (24-120p). New with Firmware update 1.0.5.1.
Recording Selection
- System Frequency
  - 59.94 Hz, 50.00 Hz, 24.00 Hz
  - 59.94 Hz mode: 59.94i/59.94P/29.97P/23.98P
  - 50.00 Hz mode: 50.00i/50.00P/25.00P
  - 24.00 Hz mode: 24.00P
- Color Gamuts*: Cinema Gamut, BT.709, BT.2020
- Gamma Curves*: Canon 709, BT.709, Wide DR, Canon Log 2, Canon Log 3, PQ, HLG
- N/A4: *Enabled for recording (including proxy) and output from each terminal
Recording / Codec
- Internal Recording: RAW Recording/ Cinema RAW Light: RAW HQ (high quality), RAW ST (standard quality), and RAW LT (light recording).
- Video Compression Formats
  - XF-AVC: MPEG-4 AVC/H.264 (10bit, 8bit (proxy))
  - MP4(HEVC): H.265/HEVC (10bit)
  - MP4(H.264) : MPEG-4 AVC/H.264 (8-bit)
- Audio Recording System
  - XF-AVC: Linear PCM (24bit, 48kHz) 4-channel recording
  - MP4 (1) : MPEG-2 AAC LC (16-bit, 48 kHz, 2-channel)
  - MP4 (2) : Linear PCM (16-bit, 48 kHz, 4-channel)
- File Format
  - XF-AVC: MXF (OP-1a)
  - MPEG4: MP4
  - HEVC: MP4
- File System
  - SDHC card: (up to 32 GB): FAT32
  - SDXC card (more than 32 GB): exFAT
  - File division unit: 4 GB for FAT32, none for exFAT
- Maximum Clip Number: 999 (per media)
Audio
- Recording Format: Linear PCM; 4-Channel; 24-Bit; 48 kHz
- Built-in Microphone: Stereo/Monaural
- External Audio Inputs
  - 2 – Mini-XLR inputs (Auto and Manual level settings)
  - External microphone terminal: (3.5 mm diameter)
- Recording Chanel Selection: Up to 4 channel audio recording is supported.
- XLR Mic Trimming: Available; -12dB, -6 dB, 0dB or +12 dB
- Limiter: Available
- Recording Level Adjustment Range: - Infinity to +18dB
- Phantom Power: Available; +48V
- Headphone Adjustment: 16 Settings; Volume is muted at lowest setting
- Built-in Speaker: Available; Volume Adjustable
- 1KHz Tone: Available (off, -12, -18, or -20 dB)
Features and Performance
- Playback
  - Clip Display: 3x4 Index Display.
  - Clip Playback: Forward Search (x5, x15, x60), Reverse Search (x5, x15, x60), Forward frame Advance,
  - Reverse Frame Advance, Record Review, Skip to next clip, skip to previous clip
  - Clip information Display: Clip Metadata display, custom picture settings
  - Playback Functions: Clip Delete
  - Photo Playback: index, single playback, delete, protect
- Special Recording Functions
  - Relay Recording*; Double-Slot Recording**
  - * Not available during Slow Motion recording
  - ** Not available in combination with slow and fast motion recording or relay recording
- Photo Recording Mode: Available; Images captured to SD Card
- Waveform Monitor
  - Available (HDR Compatible);
    - (a) Line display
    - (b) Line + spot: Line display over a red waveform in a red frame.
    - (c) Line select display
    - (d) RGB (parade)
    - (e) YPrPb (parade)
  - Output gain can be selected as either 1x or 2x. With gain set to 2x, the vertical axis (Y-position) offset value can be chosen.
  - When gamma is set to PQ, a PQ index (nits index) can be displayed. When gamma is set to HLG, an HLG index (0.0–1.0 relative index) can be displayed.
- Vectorscope: Available
- False Color: Available
- Exposure / Focus Aids: Peaking (2 types), Zebra Pattern, Magnify, Black and White Mode, Focus Guide
- Frame Record: Not Available
- Pre-Record: Yes, 3 seconds cache (Audio and Video)
- Time code: Drop Frame (DF) and Non-Drop Frame (NDF)
- Time Code Modes: Regeneration, Record Run, Free Run and External Source
- Auto White Balance (AWB): Available
- White Balance
  - Kelvin Setting:
    - 2,000K to 15,000K in 100K increment
    - -20CC to +20CC in 1 CC increments
- White Balance Presets: Daylight (5,600K); Tungsten (3,200K), Custom A, Custom B
- Auto Black Balance: Available
- Custom Picture Settings: 20
  - Custom pictures can be adjusted using the following settings and saved for later recall: Gamma, Black, Black Gamma, Low Key Saturation, Knee, Sharpness, Noise Reduction, Skin Detail, Selective Noise Reduction, Color Matrix, White Balance, Color Correction, Setup Level
  - Custom Pictures can be saved to an SD card for later use or transferring between cameras
- Custom Display: Yes; LCD panel and EVF information display can be customized
- On Screen Markers
  - Available marker options include center, horizontal, grid, aspect, safety zone, and user marker.
  - With user markers, user can set their preferred size and position.
  - Markers can be displayed in yellow, blue, green, red, black, gray, or white.
- Assign Buttons: 13 total assignable buttons on body
- Color Bars: Color bars compliant with SMPTE, EBU, or ARIB standards can be selected depending on system frequency selected
- Sensitivity
  - 59.94 Hz: f/10 (2048x1080/59.94P) or f/14 (1920x1080/29.97P)
  - 50.00 Hz: f/11 (2048x1080/50.00P) or f/16 (1920x1080/25.00P)
  - All values for ISO 800, 2000 lux, and reflectance rate of 89.9%
- Dynamic Range
  - Canon Log 2: 1600% / 16+ stops (ISO 800)
  - Canon Log 3: 1600% / 14 stops (ISO 800)
LCD Monitor
- Type
  - 3.5-inch (8.8 cm diagonal) color wide-screen LCD
  - Approx. 2,760,000 dots (1280 x RGB x 720),
- Aspect Ratio: 16:9
- Field of View Coverage: 100%
- Display Adjustments: Brightness, Contrast, Color, Sharpness, and Luminance
Input/Output
- Time code In/Out: Yes; BNC Connector (Input and Output)
- HDMI
  - Yes (Type A)
  - [4096x2160/3840x2160]/1920x1080/1280x720
- Audio Input Terminal
  - 2 – Balanced 3-pin XLR (Mic Level, Mic Level with phantom power and Line Level)
  - 3.5mm Microphone terminal
- Headphone Jack: Available; 3.5mm stereo mini-jack
- Remote Terminals
  - Remote A (Standard – LANC Compatible or RC-V100)
  - Remote Control through WiFi/LAN Adapter
- USB: Available
- CCU: Remote Controller RC-V100 (Optional)
Power
- Supply: 14.4V DC (Battery Pack)
- Power Terminal: 14.4 V DC (battery pack), 24.0 V DC (DC IN)
- Battery: BP-A Series (BP-A30, BP-A60)
- Compact Power Adapter: CA-CP200L (for Camera and Battery charger CG-A20)
Dimensions(WxHxD, excluding cable and grip belt) Body Only: Approx. 130.2 x 160 x 115.9 mm
Weight
- RF Camera body: Approx. 1.17 Kg (2.6 lbs)
- Battery Pack BP-A30: Approx. 225 g (7.9 oz.)
- Compact Power Adapter CA-CP200L: Approx. 290 g (10.2 oz.) *Not including AC cable
- Battery Charger CG-A20: Approx. 145 g (5.10 oz.)
- Mic holder unit: Approx. 56 g ( 2.0 oz.)
- Body cap: Approx. 17 g (0.60 oz.)
Temperature and Humidity
- Performance requirements: 0ºC to 40ºC, 85% (relative humidity)
- Operating requirements: -5ºC to 45ºC, 60% (relative humidity)
Language SupportEnglish, Japanese, Chinese, German, Spanish, French, Italian, Korean, Russian
Time and DateAutomatic Calendar range January 1st, 2020 through December 31, 2050
World ClockWorld Clock support – UTC time setting: Setting range from +14:00 to -12:00
