Chauvet DJ ILS Command Lighting Controller

This hardware controller has a built-in D-Fi transmitter that wirelessly controls an unlimited number of ILS-enabled fixtures.

Light up the night without setting up all day with ILS – Instant Light Shows that makes synchronizing different fixture types fast and easy without DMX. Now the ILS universe is at your command with ILS Command, a powerful controller capable of programing any ILS-enabled product. This hardware controller has a built-in D-Fi transmitter that wirelessly controls an unlimited number of ILS-enabled fixtures. Enjoy unlimited creativity as you customize, save and recall presets even in dark environments where backlit silicon buttons provide a tactile response and bright visibility. Your lighting creations are always safe because you can back up, restore and update the controller’s software using the built-in USB port and ensure unauthorized access is blocked by enabling the onboard lockout. An innovative follow spot mode highlights grand entrances without interrupting the rest of the show and a built-in audio connector allows for better accuracy when triggering lights to the beat. Manually override the show on the fly using the 9 quick color access buttons. Safely transport the controller with the included carry case.

Chauvet DJ ILS Command Features

• Powerful ILS controller capable of programing any ILS-enabled product
• Built-in D-Fi transmitter controls an unlimited number of ILS-enabled fixtures
• Customize, save and recall presets without using DMX
• Backlit silicon buttons provide a tactile response in dark environments
• Innovative follow spot mode highlights grand entrances without interrupting the rest of the show
• Backup, restore and update the controller’s software using the built-in USB port
• Ensure unauthorized access is blocked by enabling the onboard lockout
• Built-in audio connector allows for better accuracy when triggering lights to the beat
• Manually override the show on the fly using the 9 quick color access buttons
• Safely transport the controller with the included carry case

• Chauvet DJ ILS Command Lighting Controller1
• External power supply1
• USB-C cable1
• Carry bag1
• Quick Reference Guide1

• Max Unobstructed Distance600 ft (183 m)
• Operating Frequency2.412 to 2.484 GHz
• Weight3.6 lbs (1.6 kg)
• Size12.3x9.9x0.7” (313x252x19mm)
• ApprovalsCE, UKCA, RoHS, FCC
• ILS Connectors3-pin XLR
• Programmable Presets6
• Cable Length20" (508 mm)
• Input Voltage (USB-C)5V, 1A

More about Chauvet DJ's ILS Series

With the push of a button, the Instant Light Shows (ILS) creates coordinated, wireless light shows across unlimited ILS-compatible fixtures. To use ILS with ILS-compatible fixtures, the GigBAR Move + ILS fixture is required as the brains of the operation.

Working with ILS fixtures helps you go from gig bag to showtime in minutes. The GigBAR Move + ILS is a pre-mounted, all-in-one system that mounts to an included tripod, making it easy to configure the central operation of your ILS setup. Once the GigBAR Move + ILS is set up, you can sync an unlimited number of ILS-compatible fixtures without DMX. This auto-sync feature makes the pairing process fast and easy, eliminating cable mess from DMX cords, and saving time programming. With that complete, you’re ready to rock!

Curious about how to integrate ILS into your lighting setup? Contact the SoundPro experts at 800.203.5611.
