Chauvet DJ Swarm 5 FX ILS Multi-Effect Fixture

The GigBAR Move + ILS (sold separately) is required to use ILS with this fixture.

Bring excitement to any party with the Chauvet DJ Swarm 5 FX ILS. You can create an impressive variety of displays from this 3-in-1 LED light since it offers an RGBAW rotating derby, red/green laser, and white strobe effect.

Control the Swarm 5 FX ILS however it works best for your setup. Compatibility with ILS makes it easy to create coordinated light shows across different fixture types. D-Fi USB compatibility allows for wireless master/slave or DMX control. The Swarm 5 FX ILS also offers automated and sound-activated programs for a light display that operates while you’re busy elsewhere.

Chauvet DJ Swarm 5 FX ILS Features

• 3-in-1 LED light that includes an RGBAW rotating derby, red/green laser, and white strobe effect
• ILS compatibility for use in the ILS ecosystem
• D-Fi USB compatibility for wireless Master/Slave or DMX control
• Laser projects thousands of red and green laser beams
• Operation allows for separate color and program control
• Increase control options using automated and sound-activated programs, or Master/Slave and DMX modes
• Save time running cables and extension cords by power linking multiple units
• Fits best inside the CHS-40 VIP gear bag

• Swarm 5 FX ILS Multi-Effect Fixture1
• Power cord1
• User Manual1

• DMX Channels9
• DMX Connectors3-pin XLR
• Light Source
  • (Swarm): 5 LEDs (1 red, 1 green, 1 blue, 1 amber, 1 white) 3W, (300 mA), 50,000 hours life expectancy
  • (strobe): 8 LEDs (white) 1W, (300 mA), 50,000 hours life expectancy
  • (laser): 520 nm/30 mW (green) laser diode, 650 nm/100 mW (red) laser diode
• Strobe Rate0 to 20 Hz
• Beam Angle(strobe): 17°
• Field Angle(strobe): 35°
• Coverage Angle
  • (laser): 100°
  • (Swarm): 65°
• Illuminance(strobe): 823 lux @ 2 m
• Power Linking15 units @ 120V; 26 units @ 230V
• Input Voltage100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current
  • 62W, 0.5 A @ 120V, 60 Hz
  • 62W, 0.3 A @ 230V, 50 Hz
• Weight9.8 lbs (4.5 kg)
• Size9.75x11.7x12.2" (248x298x310 mm)
• Approvals
  • CE, FDA, RoHS, UKCA
  • Classified per EN/IEC 60825-
  • Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice

More about Chauvet DJ's ILS Series

With the push of a button, the Instant Light Shows (ILS) creates coordinated, wireless light shows across unlimited ILS-compatible fixtures. To use ILS with ILS-compatible fixtures, the GigBAR Move + ILS fixture is required as the brains of the operation.

Working with ILS fixtures helps you go from gig bag to showtime in minutes. The GigBAR Move + ILS is a pre-mounted, all-in-one system that mounts to an included tripod, making it easy to configure the central operation of your ILS setup. Once the GigBAR Move + ILS is set up, you can sync an unlimited number of ILS-compatible fixtures without DMX. This auto-sync feature makes the pairing process fast and easy, eliminating cable mess from DMX cords, and saving time programming. With that complete, you’re ready to rock!

Curious about how to integrate ILS into your lighting setup? Contact the SoundPro experts at 800.203.5611.
