dBTechnologies FMX-12 12-Inch Powered Stage Monitor

A new generation for flagship wedge Flexsys, the FMX series encompasses a range of tailored monitoring solutions featuring coaxial design, precise dispersion pattern, last-generation sound processing with linear phase FIR Filters and maximum adaptability to the needs of every performer.

FMX 12 is an active 2-way coaxial stage monitor equipped with 600 RMS Class D amplifiers. The wedge’s coaxial acoustic design, together with its custom horn design and advanced DSP featuring linear phase FIR filters, provides an even, highly-intelligible sound. The FMX horn design allows a very precise dispersion pattern (60° horizontal and 90° vertical) which can be easily reversed by rotating the horn, adapting the wedge to the habits of the user.

Eight on-board presets optimize EQ for different needs making FMX a skilful yet easy-to-use tool for performers of every kind. Peculiar front-rear grille design, a single handle integrated on the bottom side of the plywood cabinet and a 36mm pole mount on side panel further enhances FMX versatility.

dB Technologies FMX-12 Features

• Active 2-way stage monitor
• Coaxial configuration
• Linear phase FIR Filters
• Ultra-precise directivity
• Rotatable horn (90°x60° or 60°x90° dispersion)
• Front-rear grille design
• Integrated handle on bottom side

• FMX-12 12" 2-way powered coaxial stage monitor1

• Speaker type2-way active coaxial stage monitor
• Frequency response (-10dB)52-19,000Hz
• Max SPL128dB
• HF1", 1.3" vc
• Directivity60°x90°
• Hornrotatable
• LF12", 2" vc
• AmplifierClass D
• Peak power1200W
• ControllerDSP 28/56 bit
• AD/DA converter24 bit/48 Hz
• System presets8
• Limiterpeak, RMS, thermal
• Advanced DSPfunction FIR filters
• Crossover frequency1740Hz
• Slope LF/HF24dB/oct
• Housingplywood
• Handles1 integrated on bottom side
• Pole mount36mm
• Dimensions (WxHxD)18.3" x 11.69 x 17.48"
• Weight30.6 pounds (13.9 kg)
