Decimator DMON-16SL 16-Channel MultiViewer

The DMON-16SL is a truly portable converter, that incorporates Decimator's new easy to use LCD and button control system. This gives you easy access to most of the amazing features without using complicated LED/button control, dip switches or having to carry around a computer to change a simple setting.

Decimator DMON-16SL Features

• (NEW) Support for both 3G level A and B on the inputs.
• Low cost miniature (3G/HD/SD)-SDI 1 to 16 channel Multi-Viewer
• Custom Layouts with various standard layouts
• 16 Character UMD overlay per window with individual enables, custom positioning and size
• Audio ID overlay
• Load and restore Custom Layouts
• Fast switching between inputs using Full-Screen scaling
• Selectable output format in both Full-Screen and Multi-Viewer mode
• Low latency buffering for each input allowing non-synchronous inputs
• 16 x (3G/HD/SD)-SDI inputs with auto detection (26 Formats supported in total)
• Each window is independent of the others, allowing any 3G/HD/SD format of any frame rate to be displayed simultaneously
• Variable aspect ratios per window
• Pass-Through mode allowing any of the 16 inputs to be selected and routed to the the HDMI output
• In Pass-Through mode the selected input is passed through to the HDMI output

• DMON-16SL 16-channel multiviewer1
• Power supply1
• HDMI cable1
• USB cable1
• Heavy duty metal box1

• SDI Input Formats
  • 3G: SMPTE 424M@2.97 and 2.967Gb/s
  • 1080p@60/59.94/50Hz
  • HD:SMPTE 292M/274M/296M@1.485 and 1.435Gb/s
  • 1080i@60/59.94/50Hz
  • 1080p/psf@30/29.97/25/24/23.98Hz
  • SD:SMPTE 259M@270Mb/s
  • 625i50
  • 525i59.94
• HDMI Output Formats
  • 1080p@60/59.94/50Hz
  • 1080i@60/59.94/50Hz
  • 1080p@30/29.97/25/24/23.98Hz
  • 720p@60/59.94/50/30/29.97/95
  • 625i50
  • 525i59.94
• Power
  • +5V to +32V DC
  • Positive Centre Pin
• LCD / Button Menu Options
  • HDMI output type
  • Output Select
  • Multi-Viewer Output Format
  • Multi-Viewer Number of Windows
  • Multi-Viewer Layout
  • Multi-Viewer Audio Source
  • Multi-Viewer Reference
  • Full Screen is Scaled
  • Input Routing
  • Setup
• Inputs
  • 16x (2G/HD/SD) - SDI
  • Input Equalization > 100M using Belde n 1694A
  • USB for control and updates
• OutputsHDMI Type A
• Dimensions 8.7" x 4.1" x 1.2"
