Plug the power cord of the Juice Goose RT-REL Remote Power Controller into a switched AC outlet.
In its unpowered state, there is an internal contact between the C (common) and NC (normally closed) terminals on the unit. When 120VAC power is applied to the power cord, connection is opened between C and NC and closed between C and NO (normally open).
A common application for the RT-REL is to extend the use of a switched electrical outlet on a rack mounted power strip or sequencer or on some other device such as an audio receiver or amplifier. When plugged into the switched outlet the RT-REL can close and open a dry contact on the three position terminal strip.
Juice Goose RT-REL Features
- Extend the use of a switched electrical outlet on a rack-mounted power strip or sequencer
- When plugged into the switched outlet the RT-REL can close and open a dry contact on the three position terminal strip
- Power cord plugs into a switched AC outlet
- RT-REL Remote Power Controller1
- CHASSISDurable Plastic (Black)
- DIMENSIONS3x2x1"
- WEIGHT4.8 oz
- POWER CABLE3 Feet, 18/2 AWG with NEMA 5-15P
- RELAY CONTACT RATING (Amps)10
