Juice Goose SCV-30001 On Line Double Conversion UPS

The Juice Goose SCV-30001 On Line Double Conversion UPS's advanced processor circuitry has an output power factor of 0.90 to provide higher performance and efficiency to critical applications. High efficiency circuitry converts 90% of available current (amps) into real work (watts), reducing equipment and operating costs.

True double conversion UPS architecture completely buffers connected loads from incoming disturbances on AC line and neutral. This design also provides unconditional voltage stability regardless of problems on the local utility grid.

Easy to read LCD display provides real-time indication of all major system parameters and status, including load and battery levels and fault signals. Communications options allow remote monitoring and management.

Run time can be increased by attaching optional external batteries. Batteries can be replaced without shutting down the UPS. All unit ship with NetAgent9 management software as well as floor stand and rack mounting hardware. Installing this product requires special 30 amp electrical service.

Juice Goose SCV-30001 Features

• Double conversion, on-line UPS
• High efficiency power factor
• Programmable power outlets
• Emergency Power Off
• Hot swappable battery design
• Rack or tower installation
• User friendly and easy-shift LCD panel
• Plug and play
• Innovative battery management
• Low profile enclosure
• Ideal for broadcast/streaming, AV controllers, paging, security, data network, and transition to generator

• SCV-30001 3000VA/2700W on line double conversion UPS1

• VA / Watts3,000 / 2,700
• Battery Run Time (full load)4 mins
• Input Power PlugL5-30P
• Output Power Receptacles
  • (4) 5-20R
  • (1) L5-30R
• Input
  • Rated Volts: 100 VAC - 120 VAC
  • Low Voltage Transfer at Load Percentage: 80VAC@80% - 100%, 70VAC@70% - 80%, 60VAC@60%-70%, 55VAC 60%
  • Re-Transfer: 85VAC@80% - 100%, 75VAC@70% - 80%, 65VAC@60%-70%, 60VAC 60%
  • High Transfer: 150VAC +/-5%
  • Frequency Range: 50Hz - 60Hz
  • Power Factor: ≥ 0.99 @ Rated Voltage
• Output
  • Output Voltage (VAC): 100, 110, 115, 120 Load capacity rating is reduced at lower voltages
  • AC Voltage Regulation: +/-1%
  • Frequency Range
  • Synchronized Range: 47 - 53 Hz or 57 - 63 Hz
  • Battery Mode: 50Hz or 60Hz +/- 0.5%
  • Current Crest Ratio (CF): max. 5:1
  • Harmonic Distortion (THDU): ≤ 2% (linear load) 8% Maximum (battery mode before shutdown)
  • Transfer Time AC to DC: no transfer
  • Transfer Time Inverter to Bypass: 4ms (typical)
  • Waveform (battery mode): Pure Sine Wave
• Battery
  • Battery Type: 6) 12V/9Ah
  • Run Time (full load): 4 minutes
  • Recharging Voltage (+/-1%): 82.1VDC
  • Recharging Current (max): 4 amps
  • Typical Recharge Time: 4 hours recover to 90% of capacity
  • Typical Service Life: 3 to 5 years
• LCD Display
  • Status: Load level 0-25%, 26-50%, 51-75%, 76-100%; Low Battery/Battery Good, Progammable Management Outlets, UPS On Line, Frequency Converter, Bypass, Alarm Disabled, Battery Charger
  • Readings: Input and Output Voltage and Frequency, Battery Backup Time, Fault Indicator, Battery Voltage, Current Overload, Output Current Short Circuit
  • Control Select Buttons: Enter / UPS Off, Change Display Message, Mode Setting, Navigation Key, Mute / UPS On, Select Display
• Audible and Visual Alarms
  • Warning Indicators: Low Battery, Current Overload, Battery Not Connected, Overcharge, External Wiring Fault, EPO Enabled, Over Temperature, Charger Failure, Battery Fault, Bypass Out of Voltage Range, Bypass Frequency Fault
• Communication
  • Standard Smart RS-232/USB: Supports Windows 2000/2003/XP/Vista/2008/7, Linux, Unix and MAC
  • Optional SNMP Network Card: SNMP software and browser
  • Optional MODBUS Card: Communications from MODBUS
  • Optional AS400 Card: with DB9 or 9 pin connector
• Noise Outputless than 50dBA @ 1 meter
• Humidity20 to 90% RH (non-condensing)
• Operating Temperature32°F to 104°F (0°C to 40°C)
• Storage Temperature-13°F to 104°F (-25°C to 40°C)
• Weight65 pounds
• Dimensions (HxWxD)3.39" x 17.24" x 27.74"
