KLANG:vokal Immersive In-Ear Mixing Processor

KLANG:vokal is designed specifically to match the feature set of KLANG:kontroller but can also work as a stand alone immersive processor. Based on KLANG’s powerful, new generation, ultra-low latency FPGA core, KLANG:vokal offers 12 mixes of 24 mono or stereo inputs at 48kHz and 96kHz, including the revolutionary Root-Intensity EQs. The musicians can pick up to 24 mono or stereo channels out of 64 Dante and MADI inputs. Mixes are sent via Dante to KLANG:kontroller or can also be sent back via MADI or Dante to a mixing console.

Maximum Flexibility and user friendliness make KLANG:vokal and KLANG:kontroller the perfect match for any House of Worship or Theater application.

KLANG:vokal Immersive In-Ear Mixing Processor Features

• 12 immersive In-Ear mixes
• 24 Mono or Stereo Inputs, chosen per Mix from up to 64 Mono Inputs
• High End Personal Monitoring System
• Natural immersive sound through binaural technology
• KLANG Root Intensity EQs for all 64 Mono Inputs and all 12 Mixes

• KLANG:vokal Immersive In-Ear Mixing Processor1

• TECHNICAL SPECIFICATIONS
  • 64x64ch Dante HC (48kHz and 96kHz)
  • Processing Latency 1/4ms
  • 96 kHz | 48 kHz
  • MADI BNC Input & Output (64x64ch @48kHz or 32x32ch @96kHz)
  • Word Clock Input & Output
  • 2x USB ports (front and rear) for Updates and Showfile exchange
  • 2x Ethercon combined Dante & Control Network Ports
  • 2x Ethercon combined Dante & Control Network Ports with Multicast Filter
  • 2x RJ45 EtherCON Control Ethernet ports
  • 1x PoE enabled Dante & Control Port (front) for direct KLANG:kontroller operation
  • 1x IEC Power Supply 110–240VAC
  • 1 RU
• Weight3.6kg
• Size body44x4.5x27.5 cm
• Front panel (width)48.5cm | 19 inches
