QSC AD-C820R System Ceiling Mount Speaker
QSC AD-C820R AcousticDesign 8-Inch Ceiling Speaker System
$920.00

QSC AD-C820R AcousticDesign 8-Inch Ceiling Speaker System

SoundPro Item: 13226
MPN: AD-C820R SYSTEM
$920.00
Add to Wish List

Account manager
Contact an Account Manager for your personalized price

When you need a ceiling-mounted speaker capable of high output, look no further than QSC’s AD-C820R. This ceiling speaker system is specifically designed for music playback, public address, and distributed audio.

Maintain an accurate frequency response even in 70/100V applications with the speaker’s low-loss, low-saturation transformer. The AD-C820R measures 91dB sensitivity (1W/1m). It produces 114 dB SPL (1W/1m) output at full power.

The AD-C820R 8-Inch Ceiling Speaker System comes with an AD-C800BB acoustically optimized enclosure as well as a round or square grille, a c-ring, and a set of tile rails. The speaker assembly includes the co-entrant transducers, a 70V/100V transformer, and a crossover mounted on an ABS baffle. The speaker’s 8" woofer is equipped with a treated paper cone on a steel frame. It achieves 52 Hz via its optimized enclosure. The system achieves 90-degree axisymmetric coverage, and its high-current, low-tolerance network components provide smooth full-range, passive performance.

The AD-C820R comes with a “dog-ear” mounting system. Its conduit cover plate can be removed to access its locking 4-pole Euro-block connector; this connector accepts up to four 18AWG pairs, eliminating the hassles of star topology wiring designs.

More about QSC’s AcousticDesign Series

Easy installation, flexible mounting options, and rugged, high-weather resistance are just three of the features that set QSC’s AcousticDesign™ series apart. These premium loudspeakers are designed to give contractors and integrators versatile, reliable solutions for permanent sound installations. Unified by premium audio quality and consistent tonal characteristics this series is comprised of ceiling, surface, and pendant alternatives ideal for environments where you need the perfect combination of performance, coverage, and aesthetic appeal.

QSC AD-C820R Features

  • 8" low-frequency woofer
  • 1.4" diaphragm compression driver
  • 200 watt continuous power rating
  • 70V/100V multi-tap transformer included (system can operate in distributed or low-impedance mode)
  • AD-C820 transducer/baffle assembly for separated backcan installation
  • AD-C820 speaker baffle1
  • AD-C800BB backbox1
  • AD-C800RG round grille1
  • Low-Frequency Transducer8" ferrite woofer
  • High-Frequency Transducer1.4" neodymium compression driver
  • Frequency
    • Frequency Response (-6dB): 61Hz - 18,000Hz
    • Usable Frequency Range (-10dB): 52Hz - 18,000Hz
  • Output
    • Calculated Peak Output: 120 dB SPL
    • Calculated Continuous Output: 114 dB SPL
  • Nominal Coverage90° horizontal and vertical
  • Nominal Impedance16Ω
  • Power Rating
    • RMS Power Handling: 200 W
    • Recommended Max. Amp: 400 W
  • Sensitivity91 dB SPL, 1W/1m
  • Bass Loadingported
  • Transformer Typecustom low distortion laminated core, wide bandwidth design
  • Transformer Taps
    • 100V: 16Ω bypass, 100W, 50W, 25W
    • 70V: 16Ω bypass, 100W, 50W, 25W, 12.5W
  • Connectors
    • AD-C800BB (back box): ceramic block connector inputs and "through" connectors (rated for 400W max)
    • AD-C820 (loudspeaker baffle): 10-pin MATE-N-LOK™ connector and faston connectors
  • Dimensions
    • Diameter: 14.9"
    • Enclosure Only Depth: 8.3"
    • Enlcosure With Mounting Straps Depth: 11.2"
  • System Weight17.5 pounds
