Sennheiser EW-DP 835 SET Wireless Handheld Microphone System

The EW-DP 835 SET from Sennheiser is a portable digital UHF wireless microphone system with an SMK-S handheld transmitter and an MMD 835 cardioid dynamic microphone module. It's ideal package for filmmakers, content creators, and broadcasters, Additionally, this microphone system comes with a mounting kit that includes a mounting plate, cold shoe, belt clip, and screws, as well as a BA 70 li-ion battery, two AA batteries, a locking 3.5 mm TRS plug to 3.5 mm TRS plug cable, a locking 3.5 mm TRS plug to XLR plug cable, and a USB-C charging cable.

Choose from a variety of available frequency range options:

• Q1-6 (470 to 526 MHz)
• R1-6 (520 to 576 MHz)
• R4-9 (552 to 607 MHz)

Sennheiser EW-DP 835 SET Features

• Fully digital UHF wireless microphone system for video applications
• Integrated Bluetooth for synchronization and control
• Smart Notifications for troubleshooting and system guidance
• Intelligent battery management provides operating time (hours:minutes)
• Extended battery life: up to 12h on transmitter, 7h on receiver
• Magnetically stackable components for versatile mounting
• Industry leading 134 dB dynamic range for distortion free transmission
• Up to 56 MHz bandwidth for flexibility in any RF environment
• Exceptionally low latency (1.9 ms)
• External charging and powering via USB-C (receiver only)
• Smart Assist app for monitor & control

• EW-DP EK digital portable single channel receiver1
• EW-D SKM-S digital handheld transmitter1
• MMD 835 dynamic cardioid microphone module1
• Mounting kit (Mounting plate, cold shoe, belt clip & screws)1
• BA 70 li-ion battery 1
• AA batteries2
• Locking 3.5 mm TRS plug to 3.5 mm TRS plug cable1
• Locking 3.5 mm TRS plug to XLR plug cable1
• USB-C charging cable1

• System
  • Audio link frequency ranges
    • Q1-6: 470.2 - 526 MHz
    • R1-6: 520 - 576 MHz
    • R4-9: 552 - 607.8 MHz
    • S1-7: 606.2 - 662 MHz
    • S4-7: 630 - 662 MHz
    • S7-10: 662 - 693.8 MHz
    • U1/5: 823.2 - 831.8 MHz & 863.2 - 864.8 MHz
    • V3-4: 925.2 - 937.3 MHz
    • Y1-3: 1785.2 - 1799.8 MHz
  • Bluetooth® Low Energy (BLE) frequency range: 2402 - 2480 MHz
  • Audio frequency response: 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
  • Audio THD: ≤ -60 dB for 1 kHz @ -3 dBfs input level
  • Dynamic range: 134 dB
  • System latency: 1.9 ms
  • Operating temperature: 14°F - 131°F (-10°C - +55°C)
  • Relative humidity: 5 - 95% (non-condensing)
• EW-DP EK
  • Input voltage ~ 1.8 - 4.35 V
  • Input current
    • Typ. < 250 mA / Max. < 400
    • mA (BA 70)
    • Typ. < 400 mA / Max. < 750
    • mA (2x AA batteries)
    • < 300 mA@5 V (USB-C standalone)
  • Power Supply
    • 2x AA batteries 1.5V or BA70 rechargeable battery pack or USB-C PD power supply (max.):
      • 5V / 1500mA
      • 9V / 900mA
      • 12V / 700mA
  • Transmit power (radiated): BLE: max. 10 mW EIRP
  • Audio output power: < 2 dBV max. (high level) / < 4dBU max (high level)
  • Headphone Output: < 50 mW into 16 Ohms
  • Dimensions: 3.39x2.64x1.1" (86x67x28mm)
  • Weight (without antennas and power supply): approx. 140g (0.31 lbs)
• EW-D SK (Bodypack Transmitter)
  • Input voltage: 2.0 - 4.35V
  • Input current: < 300 mA
  • Power supply: 2 AA batteries 1.5 V (al kali manganese) or BA 70 rechargeable battery pack
  • Occupied bandwidth: 200 kHz
  • Transmit power (radiated)
    • Audio link: 10 mW ERP (Range Y1-3: 12 mW ERP)
    • BLE: max. 10 mW EIRP
  • Dimensions (without antenna): 2.48x3.15x0.79" (63x80x20mm)
  • Weight (without batteries): approx. 120g (0.26 lbs)
• MMD 835 (Microphone Capsule)
  • Transducer principle: dynamic
  • Sensitivity: 2.1 mV/Pa
  • SPL: 154 dB
  • Pick-up pattern: cardioid

More about Sennheiser's EW-DP Series

Production has enough challenges; sound doesn’t need to be one of them. A wireless microphone system that blends best-in-class technology with an ergonomic build, EW-DP will change the way you think of sound on set. Whether you’re a crew of one or many, EW-DP is the ideal partner to simplify your audio workflow and give you the confidence to focus on a successful shoot.

Fully digital UHF guarantees cutting-edge signal clarity and reliability. An innovative magnetic stacking system makes set-up a snap. Attach the cheese plate and stack receivers on top for fast and secure mounting, it’s as simple as that. Smart Notifications quickly identify missed yet critical problems that occur in your workflow. Alerts for audio clipping, low battery, blocked frequencies, muted transmitters, or unlinked devices automatically pop up so you’re never caught off guard. Auto frequency coordination locates, organizes, and maximizes frequency usage with precision ensuring you find the most reliable signal in the most efficient way possible. The Smart Assist app puts the control in the palm of your hand, allowing you to adjust your system at the camera or across the room. In short, EW-DP enables you to save valuable time and energy.

Another premium feature of EW-DP is the Sennheiser Smart Assist app, which remotely connects to your wireless system and lets you coordinate frequencies effortlessly. Use this application to enable Bluetooth Low Energy, a functionality that gives you direct control and monitoring ability from the comfort of your Android or iOS device.
