Shure AMV-LAV-Z7 Features

AMV-LAV-Z7 Replacement MoveMic Wireless Lavalier Microphone

AMV-LAV-Z7 Replacement MoveMic Wireless Lavalier Microphone1

Frequency Response 50-20kHZ +/-1dB
Dynamic Range (A-Weighted) 100dB
Equivalent Noise (A-Weighted, Camera Out = Line Level) 31 dBSPL
Equivalent Input Noise (A-Weighted, Direct to phone) 26 dBSPL
Max Sound Pressure Level (SPL) 130dBSPL
Sensitivity when used with MV-LAV (Mic Gain = 0dB) -45dBV @94dBSPL (1 Pascal RMS)
Bit Depth 24 Bit
Sampling Rate 48ksps or 44.1ksps (Host dependent)
Gain Adjustment Range 0 - 60 dB
Minimum Load Impedance - HP 16 ohms
Maximum Headphone Output Level26.4mW @1% THD
Minimum Load Impedance - Camera Out 2k ohms
Maximum Camera Output Level (Mic Setting) -26dBV
Maximum Camera Output Level (Line Setting) -8.3dBV
Latency to 3.5mm (without NR) 15.33 ms (within 1 frame @60fps)
Latency to 3.5mm (with NR) 17.33 ms
Latency to USB: Device Dependent Host Device Dependent
Range Up to 100ft (30m) line of sight
Notes* Direct to phone is only recommended for use with the MOTIV Video and Audio App(s) only. Shure recommends using the MoveMic Receiver for additional compatibility with third party apps on mobile
PHYSICAL SPECIFICATIONS (MICROPHONES)
- Overall Dimensions (w/o windscreen): 46 mm x 22 mm x 15 mm [1.81" x 0.87" x 0.59"]
- Weight (w/o windscreen): 8.2 g [0.29 oz]
- Housing Black: PC/ABS Thermoplastic
- Antenna: Sheet metal with copper-nickel-zync alloy

More about Shure’s MoveMic Series

MoveMic is a family of wireless microphones for the modern content creator, videographer and mobile journalist featuring single- and two-channel wireless lavalier microphones, as well as a separate receiver to give creators the flexibility to record to any device.
