The DSP100-2-LZ-D is an affordable amplifier with fully integrated DSP designed to optimize the speakers and overcome the acoustical limitations of a zone. The DSP100-2-LZ-D provides 100W from each channel into 8 Ohms. The robust, full function DSP includes a full cross-point mixer, EQ, filters, limiters, and more. A USB port makes programing simple, fast and repeatable for large installations. The remove volume control allows volume control from a wide range of devices. You won't find a more cost effective way to bring outstanding sound quality to two zones on the market today.
Stewart Audio DSP100-2-LZ Features
- Onboard full featured DSP
- Configurable via USB port
- Convection cooled, 1/2 rack enclosure
- 2 balanced + 2 RCA analog line/mic inputs
- 2 Dante™ input channels
- Remote Volume Control
- DSP100-2-LZ 2-Channel DSP-Enabled Amplifier1
- Three Year Warranty1
- Output Power100W x 2 @ 4/8 Ohms
- Frequency Response100 Hz - 20kHz
- THD+N<.1% @ Full Power
- Signal-to-Noise Ratio>100dB
- Input Sensivity 1V (0 dBV)
- Input impedance (Balanced/UnbalanceD)7.2K Ohms/3.6K Ohms
- Current Draw - Standby, 1/8 power 12W/65W (Varies by model)
- Amplifier Class D
- Remote Volume 0-10VDC
- External Mute Contact-Closure
- Input Connectors 3.5mm Euroblock and RCA
- Output Connectors 5mm Euroblock
- LED Indicators Power, Standby, Signal, and Clip
- Controls USB for programming, Remote Volume, Trim Knobs
- Optional Network InputDante™
- Power Supply Input 110/240 VAC 50/60Hz (Universal Input)
- CoolingConvection–Cooling (No Fans)
- Construction Aluminum Chassis
- Mounting Rack-Mountable
- Dimensions (HxWxD) 1.7x8.4x10.7 inches
- Weight 4.5lbs max (varies by model)
