The SurgeX SX20-NE/RT provides surge protection with Impedance Tolerant® EMI/RFI filtering, Inrush Current Elimination technology and remote turn-on capability. The units come in 12"x 12"x 4" NEMA enclosures and can be controlled by the SurgeX SEQ. Typical applications include home theatres, computer rooms and commercial audio/video installations of all kinds.
SurgeX SX20-NE/RT Features
- Magnetic shielding steel NEMA enclosure
- Remote turn-on capability, with voltage source for LED status indicator
- Internal barrier strip for input and output connections; accessible by KOs
- Self-test circuit with external visual indicator
- SX-20NE-RT power conditioner1
- Load Rating20A
- Voltage Rating120V
- Power Requirement (no load)15W
- Surge Let-through Voltage (6000 volt surge)0 volts
- Max. Applied Surge Voltage6000 volts*
- Max. Applied Surge Currentunlimited (due to current limiting)*
- Max. Applied Surge Energyunlimited (due to current limiting)*
- Endurance (C62.41-1991 category B3 pulses)1 KV > 500,000; 3 KV > 10,000; 6 KV > 1000
- EMI/RFI Filter (normal mode, 50Ω load)
- > 20 dB, 120 kHz – 50 MHz
- > 30 dB, 150 kHz – 50 MHz
- 11 dB @ 100 kHz; 55 dB @ 300 kHz; 72 dB @ 3 MHz; 48 dB @ 30 MHz
- EMI/RFI Filter (common mode, 50Ω load)
- > 10 dB, 350 kHz – 50 MHz
- > 20 dB, 1.8 MHz – 50 MHz
- > 30 dB, 6.25 MHz – 42 MHz
- 9 dB @ 300 kHz; 17 dB @ 1 MHz; 28 dB @ 5 MHz; 35 dB @ 20 MHz
- Auxiliary Relay Outputs2 x screw terminal
- Contact Closure Input2 x screw terminal
- Temperature Range5°C to 35°C (41°F to 95°F)
- Humidity Range5% to 95% RH non-condensing
- Dimensions (HxWxD)12" x 12" x 4"
- Weight12 pounds
