Yamaha MSP3A 4-Inch Powered Studio Monitor

The 4” MSP3A is ideal for small studios and post-production setups, as well as monitoring electronic instruments and surround reproduction.

Part of Yamaha’s innovative MSP Series of powered studio monitors, the MSP3A is a renewed design of the versatile MSP3 reference monitor, sharing its predecessor’s versatile inputs and controls, compatibility with optional support brackets (sold separately), and characterized by faithful sound reproduction via its 22W built-in amplifier. Aside from its refreshed aesthetic, new additions include a Twisted Flare Port that delivers clearer bass.

Yamaha MSP3A Features

• 4" powered studio monitor
• Ideal for stage sound systems for concert halls, entertainment venues, houses of worship, theaters, auditoriums, and more
• Mounting points for ceiling and wall mounting brackets and mic stand adapter options
• Authentic sound in a compact body
• Clear bass from unique twisted flare port technology
• Versatile inputs and controls

• MSP3A 4-Inch Powered Studio Monitor1
• Power cord1
• Owner's manual1

• Speaker Type2-way powered speaker, Bass-reflex type (Twisted Flare Port)
• Frequency Response (-10dB)67Hz - 22kHz
• Components
  • LF: 4" (10 cm) Cone
  • HF: 0.8" (2.2 cm) Dome
• Crossover4kHz
• Output power22W
• Maximum Output Level (Measured peak, IEC noise@1m)99dB SPL
• Input sensitivityLINE 1 : -10 dBu, 10kΩ (RCA), LINE 2 : +4.0 dBu, 10kΩ (Combo)
• I/O ConnectorsLINE 1 : RCA, LINE 2 : Combo (XLR/TRS phone)
• IndicatorsPower ON (Green LED)
• Power requirementsMay vary depending on region : 120V 50/60Hz, 110 – 120V 50/60Hz, 230V 50/60Hz, 220 – 230V 50/60Hz, 220V 50Hz, 240V 50Hz
• Power consumption30W
• OthersLevel control (LINE1, LINE2); Tone control (LOW: -3.0dB - +3.0dB @100Hz, HIGH: -3.0dB - +3.0dB @10kHz)
• Dimensions (WxHxD)5-5/8x9-1/4x6-5/8" (144x236x166mm)
• Net weight7.9 lbs (3.6kg)
• PackagingSingle
• Flying and mounting hardware2 x M5, Depth 15 mm (9/16")
• OptionsMic stand adaptor BMS-10A, Free-angle clamp BAS-10, Wall mounting bracket BWS20-120 / BWS20-190, Ceiling bracket BCS20-150 / BCS20-210

More about Yamaha’s MSP STUDIO Monitor Speakers

Hear honest, accurate audio with Yamaha’s monitor “STUDIO” powered loudspeaker series.

Designed with serious monitoring in mind, these monitors deliver reference-quality reproduction that gives performers instant insight into how they sound—critical information for improving and optimizing your audio in real-time!

MSP monitors are engineered to give you the consistent quality and performance to excel in professional applications of myriad shapes and sizes, handling any combination of analog and digital sources, stereo and surround sound configurations, and single or group artists.

They are ideal for stage sound systems for concert halls, entertainment venues, houses of worship, theaters, auditoriums, and more.
