Yamaha RSio64-D Dante Audio Interface

Ideal for live sound, broadcast and recording studios, post-production, and more, the RSio64-D from Yamaha is a Dante Audio Interface that converts Dante/Mini-YGDAI formats.

Yamaha RSio64-D Features

• Dante-enabled audio interface
• Accepts a wide range of Mini-YGDAI input/output and processing cards
• Seven general routing presets, including routing between Mini-YGDAI cards
• Supports matrix patching from R Remote V3 or a CL/QL series console
• Sample rate converters for all four Mini-YGDAI slots
• EXT DC INPUT for redundant power supplies
• Supports Dante redundancy (primary/secondary)

• RSio64-D Dante Audio Interface1
• Owner’s Manual1
• AC power cord1

• Sampling frequency rate: External44.1kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 48kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 88.2kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 96kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm)
• SRCSRC Lock Range: 39.7 kHz – 101.7 kHz, Sample Rate Ratio Limit: 1:2.6 to 2.6:1
• Power requirements100-240 V 50/60 Hz
• Power consumption60W
• Dimensions (WxHxD)480x88x365mm
• Net Weight6.1kg
• Operating temperature range0 - 40℃
• Storage temperature range-20 - 60℃

Streamline Your Setup with Dante

Dante connectivity allows you to seamlessly integrate it with other Dante components to create a more streamlined, efficient, and scalable network of audio gear that can easily grow or change along with your needs. The RSio64-D also supports remote setup from CL and QL series consoles.

Connectivity to Customize Your Setup

It offers up to 64 inputs and outputs each, as well as four Mini-YGDAI card slots that let you add myriad I/O formats or functions to your Dante-networked audio setup. Choose from a selection of over 30 expansion cards to customize your workflow, including AES/EBU and ADAT as well as Lake processing or Dan Dugan automatic mixing expansion cards. Each Mini-YGDAI slot includes a sample rate converter (SRC) to eliminate noise or signal interruptions from devices operating on different word clocks.

Other Features

The RSio64-D includes a primary AC IN connector that features a latched socket (V-lock) to secure the connection. An external +24V DC power source (available separately) can also be connected as a backup power supply for more confident and reliable operation in mission-critical applications.
