Specifications
Audio
Frequency Response
50 Hz to 18 kHz
Polar Pattern
Hypercardioid
Sensitivity (This SKU - W5 Mid)
2.0 mV/Pa (-54 dB re 1V/Pa)
Equivalent Acoustic Noise (W5)
39 dBA
Overload Sound Level (W5)
130 dBA SPL
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Construction
Cable Length
5 Feet
Cable Diameter
1.5mm
Cable Material
Aramid-Reinforced
Weight
Weight Without Connector
0.22 oz (6.2 g)
Weight With TA4F Connector
0.52 oz (14.8 g)
Shipping Weight
0.75 lbs
Connectivity
Connector Type
TA4F
Detachability
Fixed/Non-Detachable
Identifiers
Color
Black
Shipping Dimensions
9.125" x 5.125" x 1.375"
