Specifications
Audio
Frequency Response
50 Hz to 18 kHz
Polar Pattern
Hypercardioid
Sensitivity
W5 (mid, red band): 2.0 mV/Pa (-54 dB re 1V/Pa)
Equivalent Acoustic Noise
39 dBA
Overload Sound Level
130 dBA SPL
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Construction
Cable Length
5 Feet
Cable Diameter
1.5mm
Cable Material
Aramid-Reinforced
Color
Tan
Connector
TA4F
Detachability
Fixed/Non-Detachable
Weight
Weight Without Connector
0.22 oz (6.2 g)
Weight With TA4F Connector
0.52 oz (14.8 g)
Compatibility
Shure
BLX1, FP1, PG1, SLX1, UC1, ULX1, UR1, UR1M
Beyerdynamic
TG 1000 (gray switch), TG 100B (gray switch)
Carvin
UBP1000, UX16-BP, UXBP16
Trantec
S4.4-BTX, S5.3-BTX, S5.5-BTX
JTS
E-6TB, E-7TB(D), IN264TB, IN64TB, PG-36BG2, PT-850B, PT-850BD, PT900B, PT-920B, PT-920BG, PT-920BGmi, PT-920Bmi, PT-950, PT-950Bmi, RU-850LTB, RU-850TB, RU-988TB, RU-G3TB, UF-10TB, UF-20TB
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Shipping Weight
0.75 lbs
