Specifications
Audio
Polar Pattern
Omnidirectional
Frequency Response
20 Hz to 20 kHz
Sensitivity (W5, No Band)
7.0 mV/Pascal
Equivalent Acoustic Noise (W5)
24 dBA
Overload Sound Level (W5)
120 dB SPL
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Construction
Cable Diameter
1mm
Cable Reinforcement
Aramid-Reinforced
Cable Length
5 Feet
Boom Style
Flexible Boom With Springy Ear Section
Weight
Product Weight
0.07 oz (2 g)
Shipping Weight
0.75 lbs
Connectivity
Connector Type
TA4F (ET)
Compatibility
Compatible Transmitters
Electro-Voice BP-300, BPU-2, BPU-2Pro, BPU-2Pro-REF, BPU-R, CSB-1000, NBPU, NBPU-G, WTU-2, RE3-BPT
Identifiers
Color
Light Beige
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
