Specifications
Audio
Frequency Response (Omnidirectional)
20 Hz to 20 kHz
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity W5 Omnidirectional (no band)
7.0 mV/Pascal
Sensitivity W6 Omnidirectional (blue band)
2.0 mV/Pascal
Sensitivity W7 Omnidirectional (purple band)
0.7 mV/Pascal
Sensitivity W5 Directional (no band)
6.0 mV/Pascal
Sensitivity W6 Directional (blue band)
1.9 mV/Pascal
Sensitivity W7 Directional (purple band)
0.6 mV/Pascal
Equivalent Acoustic Noise W5
24 dBA
Equivalent Acoustic Noise W6
29 dBA
Equivalent Acoustic Noise W7
39 dBA
Overload Sound Level Omnidirectional W5
120 dB SPL
Overload Sound Level Omnidirectional W6
130 dBA SPL
Overload Sound Level Omnidirectional W7
140 dBA SPL
Overload Sound Level Directional W5
125 dBA SPL
Overload Sound Level Directional W6
135 dBA SPL
Overload Sound Level Directional W7
145 dBA SPL
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load +5V with 6.8 kOhm load +9V with 15 kOhm load
Construction
Polar Pattern
Omnidirectional
Cable Length
5 Feet
Cable Diameter
1mm Aramid-Reinforced Cable
Connector
Hirose 4 pin
Boom Style
Flexible boom and springy ear section
Color
Tan
Sensitivity Rating
Standard gain for general speaking
Weight
Unit Weight
0.07 oz (2 g)
Shipping Weight
0.75 lb
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Compatibility
Audio Technica Models
AEW-T1000, AEW-T1000a, ATW-T1001, ATW-T35, ATW-T601, ATW-T701, ATW-T75, ESW-T211
