Specifications
Dimensions
Dimensions (HxWxD)
20.3" x 18.3" x 23"
Electrical
Current Draw 230 V/115 V
-/4.0 A
Audio
Max. Peak SPL at 1m
134dB
Input Impedance
20 kΩ
Input Sensitivity
1.95 V (+8 dBu)
Audio Signal Input Connector
2 x female XLR
Audio Signal Loop Thru Connector
2 x male XLR
Connectivity
Input Type
balanced
AC Output Connector
powerCON NAC3FCB
Construction
Construction
birch plywood
Finish
ISO-flex paint
Shipping
Weight
68.3 pounds
General
Frequency Range (-10dB)
45Hz - 138Hz
Continuous
1000W
Peak
2000W
LF Driver
15LXN
Geometry
rectangular
Rigging
M10 rigging points
