DAS Audio Q-23-T 2x3-Inch 40W Passive Surface Mount Speaker | Color: Black
DAS Audio Q-23-T 2x3-Inch 40W Passive Surface Mount Speaker | Color: Black
SoundPro Item: 87589 | Part Number: Q-23-T
Usually ships in 5-7 business days
- Passive system
- Extruded aluminum enclosure
- 2 x 3”, 3P16 full-range speaker
- Dispersion H x V: 120º x 70º/90º
- SPL peak: 112 dB
- Multi-tap 100/70V transformer included
- Low/high-impedance operation
The Q-23 is a highly compact and discrete system ideal for short distances, for creating ambience, and for frontfill and under-balcony sound reinforcement. Like the other systems in the series, the Q-3 has two operating modes (voice and music) that guarantee outstanding speech intelligibility and excellent music reproduction in any acoustic environment. The aluminum enclosure and the IP-66 kit make this a highly reliable and durable choice, available in any RAL color.
- Performance
- Frequency Range (-10 dB): 150 Hz – 20 kHz
- Horizontal Coverage (-6 dB): 120º
- Vertical Coverage: Switchable: 90º -70º
- Nominal Impedance: 8 ohms
- Transformer Taps 70V: 5W – 10W – 15W
- Transformer Taps 100V: 10W – 20W – 30W
- RMS Power Handling: 40W
- Peak Power Handling: 160W
- On-axis Sensitivity 1W/1 m: 90 dB SPL
- Maximum Peak SPL at 1 m: 112 dB SPL
- Recommended Amplifier
- INTEGRAL-A402
- INTEGRAL-A404
- INTEGRAL-A1002
- INTEGRAL-A1004
- INTEGRAL-A1602
- INTEGRAL-A1604
- INTEGRAL-MA1004
- INTEGRAL-MA1604
- Recommended Processor
- INTEGRAL-M88
- INTEGRAL-MA1604
- INTEGRAL-MA1004
- Audio Input Connector 4-way Phoenix 2.54 mm
- Enclosure
- Enclosure Construction: Aluminum
- Color: Black
- IP Rating: IP66
- Dimensions (HxWxD): 7.5x4.9x4.9” (190x125x125mm)
- Net Weight: 6.2 lbs (2.8 kg)
- MF Driver 3P16
