• Wisycom BFLT1_F1-B-SC-BT2 Portable RF over Fiber Transmitter
1 1

Wisycom BFLT1_F1-B-SC-BT2 Portable RF over Fiber Transmitter

Wisycom BFLT1_F1-B-SC-BT2 Portable RF over Fiber Transmitter

SoundPro Item: 150836 | Part Number: BFLT1_F1-B-SC-BT2

$995.00
$1,106.00 $995.00
Your Price Sold out
MSRP: $1,106.00 | MAP: $995.00

Usually ships in 5-7 business days

  • Monitor & control through Bluetooth to adjust parameters in real time (Wisycom BT App)
  • Wide RF band: 170-1260 MHz
  • Operating voltage range: 9 ÷ 18 Vdc
  • 2 RGB LEDs for RF overload and system status indication
  • Easy configuration thru an high contrast OLED white display and 4 key navigation buttons
  • remote power supply from the RF connector (on ANT mode)
  • DC power for external amplifier 12V 200mA for PAW or LBP (on IFB mode)
Log in or register for YOUR best price

The Wisycom BFLT1 is an RF over Fiber transmitter. The BFLT1 can work in Antenna Mode for placement in a remote area to send signal RF back to local area with minimal loss. The BFLT1 can also be set to IFB mode, allowing the unit to work with the MTK982 and send low power single channel of IFB/IEM signal to a remote area. Once the signal reaches the remote area the PAW can be used to bring the signal up to a working level. The BFLT1 features a 4mW (6dBm) laser, allowing for coverage miles away. The BFLT1 has 20 bandpass filter options, and a 1MHz step software tunable filter to increase RF robustness in any environment. The BFLT1 offers a 12V 150mA output for powering active antennas in remote areas. Using the Wisycom BT app for iOS and Android, remote control and monitor all the settings of the BFLT1, or use the onboard navigation buttons and high contrast OLED display. The BFLT1 features SC/APC and BNC connectors for easy connection.

View full details

Specifications

Electrical
Power Consumption
BFLT1: 2 W (DC antenna booster OFF) - 3,5 W (DC antenna booster ON)
Audio
Impedance
50 Ω
Connectivity
Connector
Input: BNC-FOutput: Single Mode SC/APC
Environmental
Temperature Range
-10 - +55 °C
General
Frequency Ranges
170 - 1260 MHz
Filter Range
Selectable Modes:Tunable - 470-758 MHz, 40MHz of BWFix 1 - 940-960 MHz (US)Fix 2 - 17 Selectable Band Pass Filters
Power Supply
9 - 18 Vdc
Antenna Booster Powering
+12Vdc, 150mA max
Optical Power
6dBm [4mW]
Wavelength
1550 nm
Indicators
Display
High contrast OLED white display (128 x 64 pixels)
