Specifications
Dimensions
Dimensions (LxWxH)
8.65" x 6.5" x 9.5"
Electrical
Multi-voltage Operation
AC 100-240V, 47/63Hz
Optics
Lumens
2500
Construction
Construction
All metal construction, Locking, In/Out Power connectors, 5-pin, XLR DMX, In/Out sockets, Scissor Yoke & safety eye
Controls
6 DMX Modes
5, 8, 9, 11, 14 & 17-channel
Shipping
Weight
7.5 pounds
General
Light Source
7 x 20-Watt Quad RGBL LEDs (4-IN-1: Red, Green, Blue & Lime)
CRI
84
CRI R9
76.6
Effects
5-50 Degree Motorized Zoom, Zoom Presets (Very Narrow 6°, Narrow 10°, Medium Flood 30°, Wide Flood 40° and Very Wide Flood 50°), Linear Color Temperature Control (2700K to 7000K), Preset Color Temperatures (2700K, 3200K, 4000K, 5600K and 6500K), 16-Bit Fine Color Control (Red, Green, Blue & Lime), 64 built-in Color Macros
Control / Connections
4-button, DMX digital display on rear panel, Supports RDM (Remote Device Management), With Wired Digital Communication Network, 6 selectable Dimming Modes (Standard, Stage, TV, Architectural, Theatre & Stage 2), 4 selectable Dim Curves (Linear, Square Inv. Squa, S-Curve), Adjustable Refresh Rate (14 presets from 900 – 25,000Hz), Flicker Free operation (No flickering on camera), LED pulse and strobe effect, Quiet fan mode, WiFLY EXR Wireless DMX built-in (2500 ft. / 700M line of sight)
5 Operational Modes
Static Color Mode, RGBL Dimmer Mode, Program Mode, Sound Active Mode and DMX Controlled
Electronic Dimming
0 - 100%
Daisy Chain
10 @ 120V, 20 @ 220V
Max Power
103W
