ADJ WMX300 Standalone DMX Lighting Controller With Touchscreen

ADJ WMX300 Standalone DMX Lighting Controller With Touchscreen

SoundPro Item: 209582 | Part Number: WMX300

Regular price $929.99
Regular price $1,299.95 Sale price $929.99
Your Price Sold out
MSRP: $1,299.95 | MAP: $929.99

Usually ships in 5-7 business days

  • Broad Fixture Profile Library Controls Most Brands Through One Workflow
  • Color, Movement, And Beam Effects Engines Build Dynamic Looks Without Manual Programming
  • Music Sync Via Microphone, Line Input, Ableton Link, OS2L, Tap Tempo, Or MIDI Clock
  • Expandable Universe Count And Fixture Grouping Support Larger Rigs
  • Updated Button Mechanism Improves Tactile Response During Live Operation
  • Precision-Molded Enclosure Aligns With The Upcoming WING Expansion Controller

The WMX300 is built for mobile DJs, lighting designers, venues, and production crews who need dependable show control without carrying a laptop. It runs intelligent moving heads, LED fixtures, and effects lighting from a single unit that is compact enough for a DJ table or a VESA mount, and it works with fixtures from virtually any manufacturer.

Compared with computer-based lighting software, a standalone controller avoids depending on operating systems, drivers, and USB dongles in the middle of a live event. Compared with larger consoles, it keeps rig size and setup time down while still leaving room to grow beyond the onboard universes. That makes it a practical fit for clubs, houses of worship, rental packages, touring support rigs, and small to mid-size production work where speed and repeatability matter more than a sprawling surface.

This Mk3 revision refines the hardware over earlier WMX1 generations with a reworked industrial design. Integrators can also take advantage of the mounting pattern for fixed installs where the controller needs to sit in a booth, rack enclosure, or control position.

Downloads

View full details

Specifications

Dimensions
Product Length
7.68"
Product Width
8.66"
Product Height
2.44"
Weight
Product Weight
2.36 lbs
Electrical
USB-A Port Output
5V, 900mA
USB-C Power Input Current Required
900mA
USB-C Power Input Current Recommended For MIDI/WLINK
1500mA
Audio
Built-In Microphone
Omnidirectional electret
Line Input
3.5 mm mini-jack
Performance
Included DMX Universes
2
Maximum DMX Universes
4
Maximum DMX Channels
2,048
Maximum Fixtures
680
Fixture Profiles
15,000+
Preset Slots
200
Connectivity
3-Pin XLR DMX Outputs
2
5-Pin XLR DMX Outputs
1
5-Pin XLR DMX IN/OUT with WLINK
1
USB-A Port
MIDI, MSD, and WLINK support
USB-C Port
Power input
Construction
Housing
ABS plastic
Base Plate
Powder-coated steel
Mounting
Integrated 100 mm VESA mounting pattern
Shipping
Package Length
10"
Package Width
9.25"
Package Height
3.5"
Package Weight
1.59 lbs
