ADJ PRO700 Protégé XL LED-powered Moving Head Spot Luminaire

ADJ PRO700 Protégé XL LED-powered Moving Head Spot Luminaire

SoundPro Item: 202341 | Part Number: PRO700

$2,999.99
$4,199.95 $2,999.99
Your Price Sold out
MSRP: $4,199.95 | MAP: $2,999.99

Usually ships in 5-7 business days

Log in or register for YOUR best price
The flagship fixture of ADJ's new Protégé Series of high-performance LED-powered moving head spots, the Protégé XL is a potent luminaire which delivers up to 20,000 lumens of output. Harnessing the power of an efficient 450W LED engine with a color temperature of 7000K, the fixture incorporates a precision-engineered optical system that delivers sharp, even projections and crisp, punchy aerial effects. The Protégé XL's extensive catalog of features includes CMY + CTO color mixing, a separate color wheel, two rotating GOBO wheels, two rotating prisms (linear and circular), two frost filters (light and heavy), and an animation wheel. It offers extensive control and connectivity options, including support for DMX, sACN and Art-Net protocols as well as integrated Aria X2 wireless for cable free control and remote fixture management.
SOURCE:
  • 450W White LED Engine
  • Color Temperature: 7000K (+/-200k)
  • 20,000 Hour Average LED Life
EFFECTS:
  • Motorized Zoom: 4.1° to 45°
  • 2x Prisms: 1x 6 Facet Linear & 1x 6 Facet Circular (Overlay Capable)
  • 2x Frost Filters- 1 x Light Frost Filter and 1 x Heavy Frost Filter
  • Animation Wheel on Movable Arm
  • Motorized Focus
  • 1Hz ~10Hz Strobe Rate (Electronic)
CONTROL / CONNECTIONS:
  • (3) DMX Channel Modes (Basic / Standard / Extended)
  • DMX, sACN, ArtNet and RDM
  • Aria X2 Wireless Management System
  • NFC System
  • 6 Button Touch Control Panel
  • Full Color 180° Reversible LCD Menu Display
  • 8 / 16 Bit Resolution Adjustable Movement
  • RJ45 In/Thru Ports
  • 5 pin XLR DMX In/Out
  • IP65 Locking Power In/Out
APPROVALS / RATINGS:
  • CE
  • FCC
  • IP20
View full details

Specifications

PHOTOMETRIC DATA
Lumens
20,000
CRI
72
COLOR
Disc-Based CMY Color Mixing; Disc-Based CTO; 1 Color Wheel (7 colors)
Color Wheel Colors
Red, Blue, Green, Orange, Quad Color, Congo Blue and CTC (Color Temp. Correction)
GOBOS
2x Rotating Gobo Wheels
Each with 7 Interchangeable, glass gobos (OD
27mm, Image
16.8mm)
PAN / TILT
Pan
540/630° and separate 360° Continuous Pan Rotation
Tilt
270°
SIZE / WEIGHT
Length
15.43" (392mm)
Width
9.69" (242mm)
Vertical Height
25.55” (649mm)
Weight
59 lbs. (27kg)
ELECTRICAL / THERMAL
Electrical
AC 100-240V - 50/60Hz
Max Power Consumption
781W (7.1 Amps @ 120V., 3.5 Amps @ 230V.)
Power Link
1 unit @120V., 4 units @ 230V.
Max ambient temperature
-13°F to 113°F (-25°C to 45°C)
TECHNICAL DATA
BTU
0.74
BTU/H
2,663.21
INCLUDED ACCESSORIES
Outdoor Locking Power cable (6.5ft.)
1
Omega brackets (107mm)
2
Safety Cable, 3mm (1.97ft.)
1
