Specifications
Capsule Type
26mm Dual Diaphragm, true condenser pressure gradient
Polar Pattern
Cardioid, Omnidirectional, Figure of Eight
Sensitivity
(cardioid) 13.5mV/Pa (-37.4 dBV)
Frequency Response
20Hz - 20kHz
Electrical Impedance
≤200 ohms
Recommended load impedance
≥1000 ohms
Self-Noise Level
12dB(A) SPL
Signal to Noise
82dB re 1 Pa
Max SPL for 0.5% THD
145dB SPL
Temperature Range
-5 to 50 °C (23 to 122 °F)
Phantom Powering
48V +/-4V to IEC 61938
Current Consumption
≤5 mA
Connector
3-pin XLR (pin 2 hot)
