Specifications
Dimensions
Dimensions (W X D X H)
13.75 x 14 x 3 inches (349.25 x 355.6 x 76.2 mm)
Electrical
Voltage
100–240 V, 50/60 Hz, 1.5 A Max
Connectivity
Connectors
(4) 1/4” (6.35 mm) TRS audio outputs, (1) 1/4” (6.35 mm) TRS headphone output, (1) 1/8” (3.5 mm) TRS headphone output, (1) MIDI DIN Output/Thru-port, (2) 1/4” (6.35 mm) TRS audio inputs, (1) 1/4" (6.35 mm) TS trigger input, (2) 1/4" (6.35 mm) TRS trigger inputs, (1) 1/4" (6.35 mm) TRS HH pedal input, (2) 1/4" (6.35 mm) TRS footswitch inputs, (1) MIDI DIN Input, (1) USB Type-B port, (1) USB Type-A port, (1) power adapter input
USB Drive Supported Format
FAT32
Shipping
Weight
8.5 lbs (3.85 kg)
General
Supported File Type
16-bit, mono or stereo .WAV files, 44.1 KHz Sample Rate
Power Adapter
9 VDC, 1,500 mA
