Specifications
Dimensions
Dimensions
247x198x66mm
Packaging Size
343x302x121mm
Weight
Net Weight
2.6Kg
Electrical
Rated Power Supply
AC-110-220V
Rated Output Voltage
250W/4 Ohm, AC220V
Audio
MIC1 – 2 Input Sensitivity
5mV
AUX1 & 2 Input Sensitivity
350mV
EMC Input Sensitivity MIC
350mV
MIC Frequency Response
180Hz – 10kHz (+- 3dB)
AUX Frequency Response
70Hz -16Hz (+- 3dB)
THD
< 1% 1KHz
Connectivity
Speaker Outputs
100V or 70V & 4 Ohms – 8 Ohms-16 Ohms
Connector
Mic 1 input by Unbalanced Jack, Mic 2 Balance XLR Socket
Line 1-2 Inputs by RCA
Line output by RCA
General
Rated Power
250W
Attenuation
Microphone 1-2, Line 1-2 and Mp3/FM, bass/treble and master
Noise
< 5mV (4 Ohm load output terminal)
Protection
Short Circuit, Clip Overload and high Temp protection
Treble Adjustment
10dB (+-2)
Bass Adjustment
10dB (+ -2)
Priority
EMC>MIC1>Other
