Alfatron ALF-IPK1HD 4K AV Over IP Decoder With H.265

Alfatron ALF-IPK1HD 4K AV Over IP Decoder With H.265

SoundPro Item: 146144 | Part Number: ALF-IPK1HD

Regular price $419.99
Regular price $450.00 Sale price $419.99
Your Price Sold out
MSRP: $450.00 | MAP: $419.99

Usually ships in 5-7 business days

  • Plug-And-Play LAN Connectivity Works With Any Standard Ethernet Switch
  • Built-In Scaler Enables Fast And Seamless Source Switching Without External Hardware
  • VDirector iOS App Supports Drag-And-Drop Source Management For IP Matrix And Video Wall Setups
  • HDCP 2.2 And HDMI 1.4 Support For Compliant 4K Signal Distribution
  • Dual Audio Output Via HDMI And Line Out For Flexible System Integration
  • PoE And DC12V Power Options Simplify Cabling In Distributed Installations
  • RS232 Route Follows Video Source Switching For Unified Control System Integration

The Alfatron Electronics ALF-IPK1HD is built for AV integrators and production teams who need scalable 4K video distribution over standard network infrastructure. Using H.265 compression over a LAN input, the decoder receives and outputs 4K at 30Hz via HDMI, eliminating the need for dedicated matrix switcher hardware in mid-scale installations. The built-in scaler enables fast, seamless switching between sources without external processing, making it a practical choice for conference rooms, digital signage arrays, and multi-display environments.

The ALF-IPK1HD is designed to work with an unmanaged Ethernet switch right out of the box. No IP configuration is required, and sources can be assigned to displays via drag-and-drop using the VDirector iOS app. This management approach reduces commissioning time for integrators building IP matrix or video wall topologies. The unit supports HDCP 2.2 and HDMI 1.4, with MPEG4-AAC and LPCM stereo audio output available via HDMI or the dedicated line out. PoE and DC12V power options give installers flexibility in how they route and power units across a deployment.

Downloads

View full details

Specifications

Video
Input Port
1 x LAN
Input Resolution
Up to 4K@30Hz
Output Port
1 x HDMI
Output Resolution
Up to 4K@30Hz
Video Protocol
H.265 Video Compression
Supported Video Codecs
H.264/H.265
HDMI Version
HDMI 1.4
HDCP
HDCP 2.2
Audio
Audio Input Port
1 x LAN
Audio Output Ports
1 x HDMI, 1 x Line Out
Audio Format
MPEG4-AAC and LPCM Stereo
Electrical
Power Supply
DC12V 1A / PoE
Power Consumption
6W (Max)
ESD Protection
+/-8kV (air-gap discharge), +/-4kV (contact discharge)
Environmental
Operating Temperature
+32°F to +113°F (0°C to +45°C)
Operating Humidity
10% to 90%, non-condensing
Storage Temperature
-4°F to 140°F (-20°C to +70°C)
Storage Humidity
10% to 90%, non-condensing
Dimensions
Product Dimensions (W x H x D)
6.9" x 0.98" x 3.9" (175mm x 25mm x 100.2mm)
Shipping Dimensions (L x W x H)
6.69" x 9.05" x 2.17"
Weight
Net Weight
1.32 lbs (0.60 kg)
Shipping Weight
1.65 lbs
Identifiers
UPC
658325231076
