Alfatron ALF-VM-41 Quad HDMI Video Production Switcher
Alfatron ALF-VM-41 Quad HDMI Video Production Switcher
SoundPro Item: 147059 | Part Number: ALF-VMIX41
Usually ships in 5-7 business days
- Four HDMI Inputs With Multi-Layout Multiviewer For Full Source Monitoring
- Dual PGM Outputs Plus UVC USB Output For Simultaneous Display And Capture
- Luma And Chroma Keying Enables Overlays And Green Screen Without External Gear
- H.264 Encoder Supports Recording And Dual Network Streams With Adjustable Bitrate
- T-Bar, AUTO, And CUT Switching With Seven Transition Effects For Live Control
- Audio Delay Up To 5 Seconds Keeps External Mic Sources Sync-Accurate
- Importable Pictures And Logos For On-Air Branding Without Additional Hardware
The Alfatron Electronics ALF-VM-41 is built for AV professionals who need a capable, self-contained video production switcher without the footprint or cost of a full broadcast console. With four HDMI inputs, dual program outputs, and a UVC USB output for direct computer capture, it fits naturally into house of worship productions, corporate event streaming, educational broadcast booths, and small live event productions where a lightweight, low-power unit is an operational advantage over larger rackmount alternatives.
What separates the ALF-VM-41 from basic presentation switchers is its production-grade feature set. Luma and chroma keying allow graphic overlays and green screen compositing without external hardware. The onboard H.264 encoder supports simultaneous video recording and dual network streaming with adjustable bitrate, while the T-Bar, AUTO, and CUT switching modes with WIPE, MIX, DIP, PAT, STILL, and FTB effects give operators real transition control. Audio delay up to 5 seconds and two 3.5mm MIC/line inputs let operators manage both embedded HDMI audio and external microphone sources from a single device.
The multi-layout multiviewer, importable picture and logo media, and LAN control port make the ALF-VM-41 practical for operators who need monitoring, branding, and remote management built into one unit rather than patched together from separate components. Running on DC 7-12V at under 12W, it draws minimal power and can run from a portable supply in field applications.
