Specifications
Dimensions
Dimensions (HxWxD)
1.85x4.6x4.5″ (47x117x114mm)
Electrical
Power Requirements
7-12V DC or 9-12V AC @150mA
Audio
Frequency Response
10Hz-50KHz, +/-.5dB
THD
.01% Typical @1kHz
Input Impedance
47kΩ in Parallel with Either 100pF or 200pF
Maximum Input Level
40mVrms @1kHz
Maximum Gain
45dB @1KHz
Maximum Output Level
+6dBu (1.4Vrms)
Shipping
Weight
1.25 lbs (0.57kg)
General
Phono EQ Standard
Conforms to RIAA Curve
Hum and Noise
>90dB below clipping
In / Out Connections
RCA
Filter Type/Response
Switchable, Low Cut, -3dB @22Hz
