Specifications
Dimensions
Dimensions (HxWxD)
1.75x19x8.5″
Electrical
Power Consumption
12 W
Audio
Frequency Response
20Hz to 20kHz, +0.5dB
Input Impedance
20kΩ (bal), 15kΩ (unbal)
Maximum Input Level
+22dBm
Maximum Output Level
+18dBm (bal), +22dBm (unbal)
Signal to Noise Ratio
-94dB
Total Harmonic Distortion
0.0001
Connectivity
Input/Output Connections
Active balanced XLR and 1/4″ TRS {XLR pin 2/ 1/4″ tip = Hot (+)} Unbalanced RCA
Shipping
Weight
4.5lbs (2.5kg)
General
Channel Separation
> 50dB
Controls
Power On/Off Switch; Filter Range Switch; Bypass Switch; Level Control; AC Voltage Selector; Ground Lift Switch
Filter Type
Constant Q – 3% center accuracy
Frequency Bands
31, 1/3 octave, ISO spacing
Indicators
6dB/12dB Range LEDs; Bypass and Clip LEDs
Range
+/-6dB or +/-12dB selectable
Slider Travel
20mm w/ positive center detent
Power
Power
(Switchable) 95-130VAC, 50/60Hz
