Specifications
Dimensions
Dimensions (HxWxD)
1.75x19x6″ (4.5x48x15.2 cm)
Electrical
Power Requirements
120 V 60 Hz/50H, 10W max.
Audio
Input Impedance
10kΩ
Output Impedance
200Ω (bal), 100 Ω (unbal)
Maximum Input Level
+20 dBu Balanced
Maximum Output Level
+20 dBu Balanced
Frequency Response
10Hz to 40kHz, +/- .5dB
Total Harmonic Distortion
<0.06% (typical)
Connectivity
Input/Output Connections
¼-inch TRS balanced
Shipping
Weight
4.2 lbs (1.9 kg)
General
Side Chain Connections
¼-inch TRS (Tip = Send, Ring = Receive)
Dynamic Range
120 dB
Attack Time
.25mSec to 100mSec Adjustable
Release Time
100mSec to 3 Sec Adjustable
