- Damping Factor>380 (100Hz @ rated power @ 8 Ohms
- THD (20Hz - 20,000Hz)10dB below rated output @ 4 Ohms <0.05%
- Input Impedance12 kΩ, balanced
- Max. Input Level+21 dBu
- HPF30Hz, 50Hz, Off (12dB/Oct)
- Amplifier Protection
- Output Overcurrent
- DC Output
- Chassis Temperature
- Mains Breaker
- Front Panel
- Airflow/Cooling: front-to-rear, variable speed fan
- Front Panel Indicators: protection/clip, signal, power
- Attenuators: front panel (each channel)
- Rear Panel
- Input Connectors (each Ch): 3-pin Euroblock, XLR, 1/4" TRS phone jack
- Output Connectors: 4-pin SpeakON type (each channel)
- Power Cable Connector: 3-prong NEMA 5-15
- Ch2
- 2Ω1,000W
- 4Ω600W
- 8Ω350W
- 4Ω (Bridged)2,000W
- Power Requirements120VAC or 240VAC ±10% (factory set) 50–60Hz
- Dimensions19x3.5x16"
- Weight26.2 pounds
