Specifications
Dimensions
Dimensions
19" x 3.5" x 16"
Electrical
THD (20Hz - 20,000Hz)
10dB below rated output @ 4 Ohms <0.05%
Power Requirements
120VAC or 240VAC ±10% (factory set) 50–60Hz
Audio
Input Impedance
12 kΩ, balanced
Output Connectors
4-pin SpeakON type (each channel)
Connectivity
Max. Input Level
+21 dBu
Input Connectors (each Ch)
3-pin Euroblock, XLR, 1/4" TRS phone jack
Power Cable Connector
3-prong NEMA 5-15
Construction
Airflow/Cooling
front-to-rear, variable speed fan
Shipping
Weight
26.6 pounds
General
Damping Factor
>380 (100Hz @ rated power @ 8 Ohms
HPF
30Hz, 50Hz, Off (12dB/Oct)
Amplifier Protection
Output Overcurrent, DC Output, Chassis Temperature, Mains Breaker
Front Panel Indicators
protection/clip, signal, power
Attenuators
front panel (each channel)
Ch
2
2Ω
2000W
4Ω
1400W
8Ω
850W
4Ω (Bridged)
4000W
