AtlasIED CLA202 200W Two Channel Multi Impedance Amplifier

AtlasIED CLA202 200W Two Channel Multi Impedance Amplifier

SoundPro Item: 145815 | Part Number: CLA202

$753.99
$937.99 $753.99
Your Price Sold out
MSRP: $937.99 | MAP: $753.99

Usually ships in 5-7 business days

  • Patented Power Share Technology Assigns Independent Power Levels Per Channel
  • Dual Load Configurations Support 2Ω, 4Ω, 8Ω, And 70V Constant Voltage In One Unit
  • Class D Topology With Switch Mode Power Supply For High Efficiency
  • Direct Coupled Output Stage Maintains Thermal Stability Across All Loads
  • Convection Cooling With Variable Speed Fan Assist Minimizes Operating Noise
  • Rear Attenuators And GPI Ports Enable Remote Control And System Integration
  • Compact 1RU Half Rack Format Fits Standard Equipment Enclosures
Log in or register for YOUR best price

The AtlasIED CLA202 serves installed sound contractors, system integrators, and live sound engineers who need one amplifier to handle both constant voltage distributed systems and direct low-impedance speaker loads. Power Share is a patented innovation that lets you run each channel at different power levels—100W, 175W, 150W, or 125W—while independently selecting load impedance (2, 4, 8 ohms, or 25V/70.7V/100V). This eliminates the need for separate amplifiers in mixed-load installations.

Built with Class D topology and a switch-mode power supply, the CLA202 delivers high output voltage and current simultaneously across virtually any speaker load. The output stage uses direct-coupled thermal transfer design to maintain stable performance under varying conditions. Fan cooling engages only when needed, minimizing noise in spaces where the amplifier runs lightly loaded. With less than 1W standby consumption, it meets Energy Star standards for installations where power efficiency matters.

Rear-panel switches configure each channel's power level and load type instantly—no software or external controllers required. Five GPI ports and rear attenuators enable remote priority mute, level control, and system integration. At 1RU half-rack width, the CLA202 fits standard equipment racks and compact installations where space is constrained.

Downloads

View full details

Specifications

System
Type
2 Channel Power Amplifier
Topology
Class D
Output Power
200W
Number Of Inputs
2
GPI Ports
5, Euro Block 3.5mm
Output Speaker Terminals
2, Removable Euro Block, 5.08mm Pitch, Locking
Audio
THD At 1 kHz, 1dB Below Rated Power
≤0.15%
Signal To Noise Ratio, 8 Ohm
>93dBA Below Rated Output (A-Weighted)
Dimensions
Rack Space
1 RU, 8.5" Wide (half rack)
Height
1.75"
Width
8.75"
Depth
13.5"
Weight
Product Weight
5.3 lbs
Shipping Weight
8.5 lbs
Cooling
Idle Mode
Convection
Audio Signal Sense
Fan, Variable
Shipping
Height
4.5"
Width
17.25"
Depth
11.75"
Warranty
Warranty Period
36 months from date of purchase
