Specifications
Performance
Frequency Range (-10dB)
50Hz - 20kHz
Frequency Response (+/- 3dB)
62Hz - 19kHz
System Sensitivity (1W @ 1m)
91dB
Nominal Coverage Angle (-6dB)
100°
Directivity Index (dB)
5.6
Power
Average Power Handling
80W
Programme Power Handling
160W
Peak Power Handling
320W
Recommended Amplifier Power
160W @ 8 Ohms
Nominal Impedance
8 Ohms
Transformer Taps
60W, 30W, 15W (7.5W 70V) & Low Z operation
Maximum SPL
Average SPL
110dB
Peak SPL
116dB
Average SPL with Max. Transformer Tap
109dB
Warranty
Warranty Period
60 months from date of purchase
