Specifications
Performance
Frequency Range (-10dB)
44Hz - 30kHz
Frequency Response (+/- 3dB)
59Hz - 25kHz
System Sensitivity (1W @ 1m)
92dB
Nominal Coverage Angle (-6dB)
90°
Directivity Index (dB)
7.5
Power
Average
90W
Programme
180W
Peak
360W
Recommended Amplifier Power
180W @ 8 Ohms
Nominal Impedance
8 Ohms
Transformer Taps - Via Rotary Selector Switch
60W, 30W, 15W (7.5W 70V) & Low Z operation
Maximum SPL
Average
112dB
Peak
118dB
With Max. Transformer Tap - Average
110dB
Warranty
Warranty Period
60 months from date of purchase
