AtlasIED Drop Tile Speaker Package Ceiling Grid Install System | 6" x 2'
AtlasIED Drop Tile Speaker Package Ceiling Grid Install System | 6" x 2'
SoundPro Item: 15279 | Part Number: DT6
Usually ships in 5-7 business days
- Pre-Assembled All-In-One Unit Drops Into Ceiling Grids to Cut Installation Labor
- UL1480 And UL2043 Listings Support Plenum-Rated Commercial Ceiling Deployments
- Built-In 25V / 70.7V Transformer With Selectable Taps Suits Distributed Audio Zones
- Solid White Punched Grille Panel Maintains Aesthetic Continuity With Acoustic Ceiling Tiles
- Five Selectable Power Taps Allow Per-Zone Level Matching Without External Attenuation
The AtlasIED Drop Tile Speaker Package is engineered for integrators and commercial AV installers who need a reliable, low-labor solution for large-scale paging and background music systems. Designed for deployment in shopping malls, department stores, retail chains, and other commercial environments where dozens or hundreds of speaker locations must be addressed efficiently, the system eliminates the typical multi-component ceiling speaker installation process.
Each unit ships as a complete, pre-assembled package containing the speaker with integrated transformer, enclosure, and white grille panel — ready to drop directly into standard acoustic ceiling grid systems. The built-in 25V/70.7V transformer supports distributed audio systems commonly used in commercial installations, with selectable wattage taps to match zoning requirements. The solid white punched grille panel is designed to blend with standard acoustic tiles, preserving building aesthetics without requiring custom finishing work.
For AV integrators managing multi-zone commercial installs, the all-in-one configuration reduces per-unit labor time significantly compared to specifying separate drivers, baffles, and grilles. UL1480 and UL2043 listings make this package compliant for plenum-rated ceiling installations, a critical requirement for commercial building code compliance in most jurisdictions.
