AtlasIED FA136 6" Coaxial In-Ceiling Speaker 50-Watt 8 Ohm
AtlasIED FA136 6" Coaxial In-Ceiling Speaker 50-Watt 8 Ohm
SoundPro Item: 15504 | Part Number: FA136
Usually ships in 5-7 business days
- Kevlar Fiber-Reinforced Woofer With Norsorex Surround For Durability And Weather Resistance
- Ferrofluid-Cooled Dome Tweeter Ensures Smooth High-Frequency Response And Thermal Protection
- Patented Single-Screwdriver Mounting System Reduces Installation Labor On Large Deployments
- Coaxial Point-Source Design Achieves Wide Dispersion Comparable To Larger Enclosures
- Compatible With Full AtlasIED Enclosure And Transformer Ecosystem For Complete System Builds
- Hardware-Free Push-On Grille Installation Speeds Up Finish Work On Commercial Projects
- UL1480 Safety Listing Meets Commercial And Institutional Specification Requirements
The AtlasIED FA136 is engineered for installed audio environments where high-fidelity ceiling coverage and reliable system integration are non-negotiable. Audio integrators specifying commercial spaces, houses of worship, hospitality venues, and corporate AV installations will find this coaxial driver delivers consistent, wide-dispersion coverage from a compact 6" footprint without sacrificing frequency extension or power handling.
The coaxial topology positions a mylar-diaphragm, ferrofluid-cooled dome tweeter on a post-mount directly in front of the Kevlar fiber-reinforced polypropylene woofer, ensuring point-source coherence across the listening plane. The Norsorex synthetic rubber surround provides effective damping and weather resistance, making this driver viable in humidity-variable environments. The patented mounting system uses rotating clamps adjustable with a single screwdriver, reducing installation labor significantly on large-scale deployments.
The FA136 is designed as part of a complete system ecosystem: it front-loads into the acoustically matched FA97-6 deep backbox or the low-profile FA95-6 enclosure for depth-constrained ceilings, and accepts optional 70V/100V transformers for distributed audio runs. Hardware-free push-on grilles with serrated studs complete the clean install. UL1480 listing satisfies life-safety and specification requirements across commercial and institutional projects.
Specifications
