AtlasIED TSD-MIX32RL 3x2 Stereo Line Mixer With Remote Level
AtlasIED TSD-MIX32RL 3x2 Stereo Line Mixer With Remote Level
SoundPro Item: 20010 | Part Number: TSD-MIX32RL
Usually ships in 5-7 business days
- Three Stereo Inputs Accept Both RCA And 3.5mm Sources For Flexible Signal Routing
- Balanced Outputs Drive Long Cable Runs Without Noise Pickup
- Remote Master Level Control Enables End-User Volume Management Away From The Rack
- Bass And Treble Shelving EQ Provides Tonal Adjustment Without External Equipment
- Input And Output Indicator LEDs Simplify System Commissioning And Fault-Finding
- Compatible With AtlasIED TSD Power Supply Ecosystem To Reduce Rack Power Supply Count
- Separate Ground Connections Help Eliminate Hum In Multi-Source Installations
The AtlasIED TSD-MIX32RL is designed for AV integrators deploying distributed audio in restaurants, conference rooms, schools, and similar commercial environments where multiple stereo line sources must be summed cleanly before reaching a preamp or amplifier. Three unbalanced stereo inputs accept both RCA and 3.5mm sources, while balanced and unbalanced outputs give installers flexibility to drive long cable runs without noise pickup — a practical advantage in multi-zone installations with significant distances between rack and speaker zones.
Onboard bass and treble shelving controls allow basic tonal adjustments at the device level, reducing reliance on additional outboard EQ in simpler systems. The remote master level control capability makes the TSD-MIX32RL a strong fit for any space where end users need volume management without direct access to the equipment rack. Input signal indicators and output peak LEDs simplify commissioning and ongoing troubleshooting without external metering gear.
The unit is part of AtlasIED's Time Saving Device ecosystem, allowing a single 24VDC power supply to serve multiple TSD units simultaneously — reducing rack space and power supply count in multi-device installs. Power supply is sold separately; the TSD-MIX32RL draws 60mA, making it compatible with any available AtlasIED TSD power supply. A three-year warranty supports long-term deployment confidence in permanent installation environments.
Specifications
