AtlasIED TSD-MIX42RT 4x2 Mic/Line Mixer With Priority Paging
AtlasIED TSD-MIX42RT 4x2 Mic/Line Mixer With Priority Paging
SoundPro Item: 20013 | Part Number: TSD-MIX42RT
Usually ships in 5-7 business days
- Priority Paging Via VOX Or Contact Closure Automatically Mutes Assignable Background Sources
- Switchable Phantom Power Enables Use Of Condenser Microphones On The Balanced Mic Input
- Defeatable High Pass Filter On Mic Input Reduces Bass Rumble And Low-Frequency Feedback
- Variable Output Limiter Prevents Clipping When Mixing Sources With Inconsistent Levels
- Remote Level Control Compatible With WPD-VC10K And AAVC-10K Wall Plate Controls
- Optional WPD-MIX42RT Wall Plate Enables Remote Source Selection And Volume Adjustment
- Multiple Units Can Share One External Power Supply Based On System Current Requirements
The AtlasIED TSD-MIX42RT is designed for systems integrators and installed audio engineers who need reliable multi-source mixing with intelligent paging override in commercial environments. It serves meeting rooms, digital signage installations, luxury suites, and any facility requiring coordinated paging that can automatically mute background music sources.
The mixer accepts one balanced mic/line input via Phoenix connector and three unbalanced stereo 3.5mm line inputs, offering both switchable phantom power for condenser microphones and a defeatable high pass filter on the mic input to control low-frequency noise. Priority paging via contact closure or VOX trigger on Input 1 mutes assignable inputs, ensuring announcements are never masked by music playback. The variable output limiter reduces clipping when mixing sources with inconsistent levels — a common challenge in multi-zone installed systems.
Remote integration is a standout capability: the TSD-MIX42RT pairs with the optional WPD-MIX42RT wall plate for remote source selection and volume, and supports the AAVC-10K or WPD-VC10K for independent remote level control of the master bus or individual inputs. Multiple TSD units can share a single external power supply sized to current requirements, making it cost-effective to scale across zones. This combination of automatic priority routing, remote controllability, and low-noise mic preamp performance makes the TSD-MIX42RT a practical choice over simpler passive mixers or consumer-grade units that lack paging logic.
Specifications
