ATLONA AT-HDR-CAT-4ED 4K/Hdr Hdmi 2.0B Hdbaset Hdmi 1X4 Exten Distance Distribution Amplifier
ATLONA AT-HDR-CAT-4ED 4K/Hdr Hdmi 2.0B Hdbaset Hdmi 1X4 Exten Distance Distribution Amplifier
SoundPro Item: 138604 | Part Number: AT-HDR-CAT-4ED
Usually ships in 5-7 business days
- Connectivity Technology: Wired
- Number of Input Devices Supported: 1
- Maximum Operating Distance: 330 ft
- Graphics Modes: 4K
- Maximum Video Resolution: 4096 x 2160
- Network (RJ-45): Yes
- HDMI In: Yes
- HDMI Out: Yes
- USB: Yes
- Number of Network (RJ-45) Ports: 5
- Number of USB Ports: 1
- Number of HDMI Inputs: 1
- Number of HDMI Outputs: 1
- Media Type Supported: Twisted Pair
- Twisted Pair Cable Standard: Category 7
- Transmitter Height: 1.73"
- Transmitter Width: 8.64"
- Transmitter Depth: 10"
- Form Factor: Surface-mountable
The Atlona AT-UHD-CAT-4ED distribution amplifier features pass-through HDMI input connections, four extended distances, Ethernet-enabled HDBaseT outputs, and display control capability. Each output transmits AV and control signals up to 330 ft. (100 m). Features include 4K/UHD @ 60 Hz with 4:2:0 color subsampling, HDCP 2.2 compliance, EDID management, and PoE for powering remote receivers. A wide variety of consumer displays may be controlled by the UHD-CAT-4ED using CEC. Designed for commercial distribution applications, the UHD-CAT-4ED is control system-friendly and integrates with any TCP/IP, RS-232, or IR control system, and features a 1U, half-rack width enclosure with external, international power supply. Compatible Atlona receiver: AT-UHD-EX-100CE-RX. Signal distribution applications increasingly require compatibility with HDCP 2.2, 4K/UHD @ 60 Hz support with 4:2:0 color subsampling to ensure images reach displays with compatible copy protection and with the pristine digital image quality of the original signal, without artifacts resulting from inferior image distribution systems. HDBaseT distribution ensures reliable, long-distance transmission of high-resolution audio and video signals. These core features along with added display control provide additional flexibility. Power over Ethernet not only provides compatibility with Atlona Extender products but enables HDBaseT Certification.
