Specifications
With NEXO Processing
Frequency Response @-6 dB
75 Hz to 160 Hz
Peak SPL@1m
146 dB Peak
Operating Voltage
65 Vrms (180 Vpeak)
Crossover Frequency
75 Hz
Nominal Impedance
4 Ohms
Components
2 x Neodymium 18” 8 Ohms
Connectors
2 x NL4, 4 poles connectors
Rigging points
2 x universal accessory fit (on each side) + 1 x M20 thread for Pole Stand on top
Material
Custom made bent plywood of baltic birch and poplar
Finish
Black or White structural paint
Front Finish
Magnelis® Steel front grille
Height x Width x Depth
594mm x 755mm x 905 mm (23.4” x 29.7” x 35.6”)
Weight: Net
77 kg (170 lbs)
Operating temperature range
0°C - 40 °C (32° F - 104° F)
Storage temperature range
-20 °C - 60 °C (-4 ° F - 140° F)
System Operation
Powering solution
NXAMP4x4mk2 Powered TDcontroller: Up to 2 x B218 per channel
Optional powering solution
NXAMP4x1mk2 Powered TDcontroller (Bridged): Up to 2 x B218 per bridged channels
