Specifications
Dimensions
Dimensions
6.5 inches (165 mm) long, 2.17 inches (55 mm) maximum diameter
Electrical
Phantom Power Requirements
11-52V DC, 3 mA typical (condenser)
Audio
Polar Pattern
Cardioid
Frequency Response
20 Hz - 17 kHz (Condenser), 30 Hz - 10 kHz(Dynamic)
Signal-to-Noise Ratio
70 dB, 1 kHz at 1 Pa (condenser)
Connectivity
Maximum Input Sound Level
158 dB SPL, with 10 dB pad (nominal)
Connector
5-pin XLRM
Construction
Cable
16.5' (5 m) dual shielded, 8-conductor cable, 5-pin XLRF-type connector at microphone, two 3-pin XLRM-type output connectors
Shipping
Weight
13.8 oz (390 g)
General
Transducer Type
Dual Element (Condenser, Dynamic)
Condenser
-51 dBV/Pa (2.8 mV)
Dynamic
-54 dBV/Pa (1.9 mV) re 1V at 1 Pa
Dynamic Range
124 dB, 1 kHz at Max SPL (condenser)
Switches
(Condenser Only) High-pass filter, 10 dB pad (nominal)
Low-Frequency Roll-Off
80 Hz, 12 dB/octave (condenser)
